Camera
|
|
Image Sensor
|
5MP CMOS
|
|
Max. Resolution
|
2880 (H) × 1620 (V)
|
|
Pixel
|
5MP
|
|
Scanning System
|
Progressive
|
|
Electronic Shutter Speed
|
PAL:1/3 s–1/100,000 s
NTSC:1/4 s–1/100,000 s
|
|
S/N Ratio
|
> 65 dB
|
|
Min. Illumination
|
0.001 Lux/F1.0, 0 Lux warm light on
|
|
Illumination Distance
|
20 m (65.61 ft)
|
|
Illuminator On/Off Control
|
Auto; manual
|
|
Illuminator Number
|
1
|
|
Pan/Tilt/Rotation Range
|
Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°
|
|
Lens
|
|
Lens Type
|
Fixed lens
|
|
Mount Type
|
M12
|
|
Focal Length
|
2.8 mm; 3.6 mm
|
|
Max. Aperture
|
F1.0
|
|
Field of View
|
2.8 mm: H: 112°; V: 57°; D: 132°
3.6 mm: H: 88; V: 46°; D: 104°
|
|
Iris Type
|
Fixed iris
|
|
Close Focus Distance
|
2.8 mm: 1.6 m (5.25 ft);
3.6 mm: 2.3 m (7.5 ft)
|
|
DORI Distance
|
Lens
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
2.8 mm
|
67.4 m
(212.3 ft)
|
27.0 m
(88.6 ft)
|
13.5 m
(44.3 ft)
|
6.7 m
(22.0 ft)
|
|
3.6 mm
|
80.0 m
(262.5 ft)
|
32.0 m
(105.0 ft)
|
16.0 m
(52.5 ft)
|
8.0 m
(26.2 ft)
|
|
Video
|
|
Frame Rate
|
CVI:
PAL: 5M@25 fps; 4M@25 fps; 1080p@25 fps
NTSC: 5M@25 fps; 4M@30 fps; 1080p@30 fps
AHD:
PAL: 4M@25 fps;
NTSC: 4M@30 fps
TVI:
PAL: 4M@25 fps;
NTSC: 4M@30 fps
CVBS:
PAL: 960H;
NTSC: 960H
|
|
Resolution
|
5M (2880 × 1620); 4M (2560 × 1440); 1080p (1920 × 1080); 960H (960 × 576/960 × 480)
|
|
BLC
|
BLC/HLC/WDR/HLC-Pro
|
|
WDR
|
120 dB
|
|
White Balance
|
Auto; manual
|
|
Gain Control
|
Auto; manual
|
|
Noise Reduction
|
3D NR
|
|
Smart Light
|
Yes
|
|
Mirror
|
Off/On
|
|
Privacy Masking
|
Off/On (8 areas, rectangle)
|
|
Certifications
|
|
Certifications
|
CE (EN55032, EN55024, EN50130-4,EN60950-1)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No.60950-1)
|
|
Port
|
|
Video Output
|
Video output choices of CVI/TVI/AHD/CVBS by one BNC port
|
|
Audio Input
|
One channel built-in mic (-A)
|
|
Power
|
|
Power Supply
|
12 V ±30% DC
|
|
Power Consumption
|
Max 4.4 W (12 V DC, warm light on)
|
|
Environment
|
|
Operating Temperature
|
–40 °C to +60 °C (–40 °F to +140 °F); < 95% (non-condensation)
|
|
Storage Temperature
|
–40 °C to +60 °C (–40 °F to +140 °F); < 95% (non-condensation)
|
|
Protection Grade
|
IP67
|
|
Structure
|
|
Casing
|
Metal front cover + plastic main body + plastic bracket
|
|
Camera Dimensions
|
161.3 mm × 69.7 mm × 70.0 mm (6.35" × 2.75" × 2.75")
|
|
Net Weight
|
0.23 kg (0.51 lb)
|
|
Gross Weight
|
0.33 kg (0.73 lb)
|
