Camera
|
|
Image Sensor
|
2MP CMOS
|
|
Max. Resolution
|
1920 (H) × 1080 (V)
|
|
Pixel
|
2MP
|
|
Scanning System
|
Progressive
|
|
Electronic Shutter Speed
|
PAL: 1/3 s–1/100,000 s
NTSC: 1/4 s–1/100,000 s
|
|
S/N Ratio
|
> 65 dB
|
|
Min. Illumination
|
0.0002 Lux/F1.0, 0 Lux White Light on
|
|
Illumination Distance
|
60 m (196.9 ft)
|
|
Illuminator On/Off Control
|
Auto; manual
|
|
Illuminator Number
|
4
|
|
Pan/Tilt/Rotation Range
|
Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°"
|
|
Lens
|
|
Lens Type
|
Fixed lens
|
|
Mount Type
|
M12
|
|
Focal Length
|
2.8 mm; 3.6 mm; 6 mm
|
|
Max. Aperture
|
F1.0
|
|
Field of View
|
2.8 mm: H: 106°; V: 55°; D: 125°
3.6 mm: H: 84°; V: 44°; D: 99°
6 mm: H: 57°; V: 31°; D: 65°
|
|
Iris Type
|
Fixed iris
|
|
Close Focus Distance
|
2.8 mm: 1 m (3.3 ft)
3.6 mm: 1.7 m (5.6 ft)
6 mm: 4.3m (14.1 ft)
|
|
DORI Distance
|
Lens
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
2.8 mm
|
44.9 m (147.3 ft)
|
17.9 m (58.7 ft)
|
8.9 m
(29.2 ft)
|
4.6 m
(15.1 ft)
|
|
3.6 mm
|
55.2 m
(181.1 ft)
|
22.1 m
(72.5 ft)
|
11.0 m
(36.1 ft)
|
5.5 m
(18.0 ft)
|
| |
6 mm
|
82.8 m
(271.7 ft)
|
33.1 m
(108.6 ft)
|
16.6 m
(54.5 ft)
|
8.3 m
(27.2 ft)
|
|
Video
|
|
Frame Rate
|
CVI:
PAL: 1080P@25fps
NTSC: 1080P@30fps
AHD:
PAL: 1080P@25fps
NTSC: 1080P@30fps
TVI:
PAL: 1080P@25fps
NTSC: 1080P@30fps
CVBS:
PAL: 960H
NTSC: 960H
|
|
Resolution
|
1080P (1920 × 1080) ; 960H (960× 576/960 × 480) ;
|
|
BLC
|
BLC/HLC/WDR/HLC-Pro
|
|
WDR
|
120dB
|
|
White Balance
|
Auto; Area white balance
|
|
Gain Control
|
Auto; manual
|
|
Noise Reduction
|
3D NR
|
|
Smart Light
|
Yes
|
|
Mirror
|
Off/On
|
|
Privacy Masking
|
Off/On (8 area, rectangle)
|
|
Certifications
|
|
Certifications
|
CE (EN55032, EN55024, EN50130-4, EN62368-1)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No.60950-1)
|
|
Port
|
|
Video Output
|
Video output choices of CVI/TVI/AHD/CVBS by one BNC port (DIP Switch)
|
|
Audio Input
|
One channel built-in mic
|
|
Power
|
|
Power Supply
|
12V ±30% DC
|
|
Power Consumption
|
Max 10.2W (12V DC, warm light on)
|
|
Environment
|
|
Operating Temperature
|
–40°C to +60°C (–40°F to 140°F) ; <95% (non-condensation)
|
|
Storage Temperature
|
–40°C to +60°C (–40°F to 140°F) ;<95% (non-condensation)
|
|
Protection Grade
|
IP67
|
|
Structure
|
|
Casing
|
Metal throughout the whole casing
|
|
Camera Dimensions
|
244.1 mm × 90.4 mm × 90.4 mm (9.61" × 3.56" × 3.56")
|
|
Net Weight
|
0.76 kg (1.68 lb)
|
|
Gross Weight
|
1.02 kg (2.25 lb)
|
