| Camera |
| Image Sensor | 1/2.7 inch CMOS |
| Effective Pixels | 2592 (H) × 1944 (V), 5MP |
| Scanning System | Progressive |
| Electronic Shutter Speed | PAL: 1/25s–1/100000s
NTSC: 1/30s–1/100000s |
| S/N Ratio | >65dB |
| Minimum Illumination | 0.02Lux/F1.8, 30IRE, 0Lux IR on |
| Fill Light Working Distance | 60 m (196.85 ft) |
| IR On/Off Control | Auto; manual |
| IR LED Number | 4 |
| Pan/Tilt/Rotation Range | Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360° |
| Lens |
| Lens Type | Motorized-focal |
| Mount Type | φ14 |
| Focal Length | 2.7 mm–12 mm |
| Max. Aperture | F1.8–F3.3 |
| Angle of View | 2.7 mm: 122° × 93° × 68° (diagonal x horizontal x vertical)
12 mm: 37° × 30° × 22° (diagonal x horizontal x vertical) |
| Iris Type | Fixed iris |
| Auto Focus | N/A |
| Close Focus Distance | 0.8 m (2.62 ft) |
| DORI Distance | Lens | Detect | Observe | Recognize | Identify |
| 2.7mm | 67.0 m (219.81 ft) | 27.0 m (88.58 ft) | 13.0 m (42.65 ft) | 6.7 m (21.98 ft) |
| 12mm | 198.0 m (649.60 ft) | 79.0 m (259.18 ft) | 39 m (127.95 ft) | 12.0 m (39.37 ft) |
| Video |
| Frame Rate | CVI:
PAL: 5M@20fps; 4M@25fps; 1080P@25fps;
NTSC: 5M@20fps; 4M@30fps; 1080P@30fps
AHD: PAL: 5M@20fps; 4M@25fps; 1080P@25fps;
NTSC: 5M@20fps; 4M@30fps; 1080P@30fps
TVI: PAL: 5M@20fps; 4M@25fps; 1080P@25fps;
NTSC: 5M@20fps; 4M@30fps; 1080P@30fps
CVBS: PAL: 960H;
NTSC: 960H |
| Resolution | 5M (2592 × 1944); 4M (2560 × 1440); 1080P (1920 ×1080); 960H (960 × 576/960 × 480) |
| Day/Night | Auto switch by ICR |
| BLC | BLC/HLC/WDR |
| WDR | DWDR |
| White Balance | Auto; manual |
| Gain Control | Auto; manual |
| Noise Reduction | 2D NR |
| Smart IR | Yes |
| Mirror | Off/On |
| Privacy Masking | Off/On (8 area, rectangle) |
| Certifications |
| Certifications | CE (EN55032, EN55024, EN50130-4,EN60950-1)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No.60950-1) |
| Port |
| Video Output | Video output choices of CVI/TVI/AHD/CVBS by one BNC port |
| Power |
| Power Supply | 12V ±30% DC |
| Power Consumption | Max 12W (12V DC, IR on) |
| Environment |
| Operating Temperature | -40°C to +60°C (-40°F to 140°F);<95% (non-condensation) |
| Storage Temperature | -40°C to +60°C (-40°F to 140°F);<95% (non-condensation) |
| Protection Grade | IP67 |
| Structure |
| Casing | Metal throughout the whole casing |
| Camera Dimensions | 209.9 mm × 90.4 mm × 90.4 mm (8.26" × 3.56" × 3.56") |
| Net Weight | 570g (1.25lb) |
| Gross Weight | 740g (1.63lb) |
