| Cámara |
| Sensor de imagen | CMOS de 2 MP |
| Máxima resolución | 1920 (alto) × 1080 (vertical) |
| Sistema de escaneo | Progresivo |
| Velocidad de obturación electrónica | PAL: 1/25 s–1/100 000 s
NTSC: 1/30 s–1/100 000 s |
| Iluminación mínima | 0,0001 lux a F1.0 (color, 30 IRE)
0,00001 lux a F1.0 (blanco y negro, 30 IRE)
0 lux (iluminador activado) |
| Relación señal/ruido | >65 dB |
| Distancia de iluminación | IR: 50 m (164,04 pies); Luz cálida: 50 m (164,04 pies) |
| Control de encendido y apagado del iluminador | Auto/Manual |
| Número de iluminador | 4 (Luz multinúcleo) |
| Ajuste del ángulo | Panorámica: 0°–360°
Inclinación: 0°–78°
Rotación: 0°–360° |
| Lente |
| Tipo de lente | Focal fijo |
| Montura de lente | M12 |
| Longitud focal | 2,8 mm; 3,6 mm |
| Apertura máxima | F1.0 |
| Campo de visión | 2,8 mm: Alto: 101,8°; V: 54,4°; Fondo: 122,1°
3,6 mm: Alto: 84,2°; V: 45,3°; Re: 98,9° |
| Iris Control | Fijado |
| Distancia de enfoque cercana | 2,8 mm: 1,1 m (3,61 pies)
3,6 mm: 1,6 m (5,25 pies) |
| Distancia DORI | | Lente | Detectar | Observar | Reconocer | Identificar | | 2,8 milímetros | 45,6 m
(149,61 pies) | 18,2 m
(59,71 pies) | 9,1 m
(29,86 pies) | 4,6 m
(15,09 pies) | | 3,6 milímetros | 55,6 m
(182,41 pies) | 22,2 m
(72,83 pies) | 11,1 m
(36,42 pies) | 5,6 m
(18,37 pies) | | *DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool. | |
| Video |
| Video Frame Rate | CVI:
PAL: 1080p@25 fps;
NTSC: 1080p@30 fps;
AHD:
PAL: 1080p@25 fps;
NTSC: 1080p@30 fps;
TVI:
PAL: 1080p@25 fps;
NTSC: 1080p@30 fps;
CVBS:
PAL: 960H;
NTSC: 960H |
| Resolution | 1080p (1920 × 1080); 960H (960 × 576/960 × 480) |
| Day/Night | Auto(ICR)/Color/B/W |
| BLC | BLC; HLC; WDR |
| WDR | 130 dB |
| White Balance | Auto |
| Gain Control | Auto |
| Noise Reduction | 3D NR |
| Motion Detection | Yes (It needs to be controlled through the XVR) |
| Illumination Mode | Yes (It needs to be controlled through the XVR) |
| Mirror | Yes (It needs to be controlled through the XVR) |
| Certification |
| Certifications | CE-LVD: EN 62368-1;
CE-EMC: EN 55032; EN 55035; |
| Audio |
| Built-in Mic | Yes, built-in dual Mic |
| Camera Audio | CVI |
| Pick-up Distance | 12 m (39.37 ft) |
| Port |
| Video Output | Video output choices of CVI/TVI/AHD/CVBS by one BNC port (DIP Switch) |
| Power |
| Power Supply | 12 VDC (±30%) |
| Power Consumption | Max 5.6 W (12 VDC, LED on) |
| Environment |
| Operating Temperature | –40 °C to +60 °C (–40 °F to +140 °F) |
| Operating Humidity | <95% (RH), non-condensing |
| Storage Temperature | –40 °C to +60 °C (–40 °F to +140 °F) |
| Storage Humidity | <95% (RH), non-condensing |
| Protection | IP67 |
| Anti-corrosion Level | Basic Protection
*The products are designed for general use and are applicable even in areas with no specific requirements for anti-corrosion protection. |
| Structure |
| Casing Material | Dome (metal + plastic) + plastic enclosure |
| Product Dimensions | Φ109.9 mm × 102.2 mm (Φ4.33" × 4.02") |
| Net Weight | 0.33 kg (0.73 lb) |
| Gross Weight | 0.45 kg (0.99 lb) |
| Installation | Wall mount; ceiling mount; vertical pole mount |
