Camera
|
|
Pixel
|
8 MP
|
|
Image Sensor
|
4K CMOS
|
|
Max. Resolution
|
3840 (H) × 2160 (V)
|
|
Scanning System
|
Progressive
|
|
Electronic Shutter Speed
|
PAL: 1/25 s–1/100000 s
NTSC: 1/30 s–1/100000 s
|
|
Min. Illumination
|
0.01 lux@F2.0 (Color, 30 IRE)
0.001 lux@F2.0 (B/W, 30 IRE)
0 lux (Illuminator on)
|
|
S/N Ratio
|
>65 dB
|
|
Illumination Distance
|
80 m (262.47 ft)
|
|
Illuminator On/Off Control
|
Auto/Manual
|
|
Illuminator Number
|
2 (IR light)
|
|
Pan/Tilt/Rotation Range
|
Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360°
|
|
Lens
|
|
Lens Type
|
Fixed-focal
|
|
Lens Mount
|
M12
|
|
Focal Length
|
2.8 mm; 3.6 mm; 6 mm
|
|
Max. Aperture
|
F2.0
|
|
Field of View
|
2.8 mm: H: 106°; V: 56°; D: 125°
3.6 mm: H: 88°; V: 46°; D: 105°
6 mm H: 55°; V: 31°; D: 62°
|
|
Iris Control
|
Fixed
|
|
Close Focus Distance
|
2.8 mm: 1.3 m (4.27 ft)
3.6 mm: 1.9 m (6.23 ft)
6 mm: 3.5 m (11.48 ft)
|
|
DORI Distance
|
Lens
|
Detect
|
Observe
|
Recognize
|
Identify
|
|
2.8 mm
|
88 m
(288.71 ft)
|
35.2 m
(115.49 ft)
|
17.6 m
(57.74 ft)
|
8.8 m
(28.87 ft)
|
|
3.6 mm
|
106.7 m
(350.07 ft)
|
42.7 m
(140.09 ft)
|
21.3 m
(69.88 ft)
|
10.7 m
(35.10 ft)
|
|
6 mm
|
154.7 m (507.55 ft)
|
61.9 m (203.08 ft)
|
30.9 m (101.38 ft)
|
15.5 m
(50.85 ft)
|
|
Video
|
|
Video Frame Rate
|
CVI:
PAL: 4K@15 fps; 5M@25 fps; 4M@25 fps; 1080p@25 fps
NTSC: 4K@15 fps; 5M@25 fps; 4M@30 fps; 1080p@30 fps
TVI:
PAL: 4K@15 fps
NTSC: 4K@15 fps
AHD:
PAL: 4K@15 fps
NTSC: 4K@15 fps
CVBS:
PAL: 960H
NTSC: 960H
|
|
Resolution
|
4K (3840 x 2160); 5M (2880 x 1620); 4M (2560 x 1440); 1080p (1920 x 1080); 960H (960 x 576/960 x 480)
|
|
Day/Night
|
Auto(ICR)/Color/B/W
|
|
BLC
|
BLC; HLC; WDR; HLC-Pro
|
|
WDR
|
120 dB
|
|
White Balance
|
Auto;Area white balance
|
|
Gain Control
|
Auto/Manual
|
|
Noise Reduction
|
3D NR
|
|
Smart Illumination
|
Smart IR
|
|
Defog
|
Electronic defog
|
|
Mirror
|
Yes
|
|
Privacy Masking
|
Off/On (8 areas, rectangle)
|
|
Certification
|
|
Certifications
|
CE-LVD: EN 62368-1;
CE-EMC: EN 55032; EN 55035
FCC: 47 CFR FCC Part 15, Subpart B;
UL: UL62368-1 + CAN/CSA C22.2 No. 62368-1-14
|
|
Port
|
|
Video Output
|
Video output choices of CVI/TVI/AHD/CVBS by one BNC port
|
|
Power
|
|
Power Supply
|
12 VDC ± 30%
|
|
Power Consumption
|
Max 6.4 W (12 VDC, IR on)
|
|
Environment
|
|
Operating Temperature
|
–40 °C to +60 °C (–40 °F to +140 °F)
|
|
Operating Humidity
|
<95% (RH), non-condensing
|
|
Storage Temperature
|
–40 °C to +60 °C (–40 °F to +140 °F)
|
|
Protection
|
IP67
|
|
Structure
|
|
Casing Material
|
Metal front cover + plastic rear barrel + metal bracket
|
|
Product Dimensions
|
240.7 mm × 90.7 mm × 90.4 mm (9.48" × 3.57" × 3.56")
|
|
Packaging Dimensions
|
299 mm × 119 mm × 111 mm (11.77" × 4.69" × 4.37")
|
|
Net Weight
|
0.41 kg (0.90 lb)
|
|
Gross Weight
|
0.62 kg (1.36 lb)
|
|
Installation
|
Wall mount; ceiling mount; vertical pole mount
|
