| Camera |
| Image Sensor | 5MP CMOS |
| Max. Resolution | 2880 (H) × 1620 (V) |
| Pixel | 5MP |
| Scanning System | Progressive |
| Electronic Shutter Speed | PAL: 1/3 s–1/100,000 s
NTSC: 1/4 s–1/100,000 s |
| S/N Ratio | > 65 dB |
| Min. Illumination | 0.001 Lux/F1.2, 0 Lux White Light on |
| Illumination Distance | 60 m (196.9 ft) |
| Illuminator On/Off Control | Auto; manual |
| Illuminator Number | 4 |
| Pan/Tilt/Rotation Range | Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360° |
| Lens |
| Lens Type | Motorized Vari-focal |
| Mount Type | φ14 |
| Focal Length | 2.7 mm–13.5 mm |
| Max. Aperture | F1.2 |
| Field of View | H: 35°–112°;
V: 19°–58°;
D: 40–137° |
| Iris Type | Fixed iris |
| Close Focus Distance | 1.5 m (4.9 ft) |
| DORI Distance | Lens | Detect | Observe | Recognize | Identify |
| 2.7 mm | 65.2 m (213.9 ft) | 26 m ( 85.3 ft) | 13 m (42.7 ft) | 6.5 m (21.3 ft) |
| 13.5 mm | 186.6 m (612.2 ft) | 74.6 m (244.8 ft) | 37.3 m (122.4 ft) | 18.6 m (61 ft) |
| Video |
| Frame Rate | CVI:
PAL: 5M@25 fps; 4M@25 fps; 1080p@25 fps
NTSC: 5M@25 fps; 4M@30 fps; 1080p@30 fps
AHD:
PAL: 4M@25 fps;
NTSC: 4M@30 fps
TVI:
PAL: 4M@25 fps;
NTSC: 4M@30 fps
CVBS:
PAL: 960H;
NTSC: 960H |
| Resolution | 5M (2880 × 1620); 4M (2560 × 1440); 1080p (1920 × 1080); 960H (960 × 576/960 × 480) |
| BLC | BLC/HLC/WDR/HLC-Pro |
| WDR | 120 dB |
| White Balance | Auto; Area WB |
| Gain Control | Auto; manual |
| Noise Reduction | 3D NR |
| Smart Light | Yes |
| Mirror | Off/On |
| Privacy Masking | Off/On (8 area, rectangle) |
| Certifications |
| Certifications | CE (EN55032, EN55024, EN50130-4,EN60950-1)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No.60950-1) |
| Port |
| Video Output | Video output choices of CVI/TVI/AHD/CVBS by one BNC port |
| Audio Input | One channel built-in mic |
| Power |
| Power Supply | 12 V ±30% DC |
| Power Consumption | Max 11.88 W (12 V DC, warm light on) |
| Environment |
| Operating Temperature | –30 °C to +60 °C (–22 °F to 140 °F); < 95% (noncondensation) |
| Storage Temperature | –30 °C to +60 °C (–22 °F to 140 °F); < 95% (noncondensation) |
| Protection Grade | IP67 |
| Structure |
| Casing | Metal throughout the whole casing |
| Camera Dimensions | 244.1 mm × 90.4 mm × 90.4 mm (9.61" × 3.56" × 3.56") |
| Net Weight | 0.79 kg (1.74 lb) |
| Gross Weight | 1.04 kg (2.29 lb) |
