| Camera |
| Image Sensor | 1/2.7 inch CMOS |
| Max. Resolution | 2880 (H) × 1620 (V) |
| Pixel | 5MP |
| Scanning System | Progressive |
| Electronic Shutter Speed | PAL: 1/25s–1/100000s
NTSC: 1/30s–1/100000s |
| S/N Ratio | >65 dB |
| Min. Illumination | 0.01 Lux/F1.6, 30IRE, 0 Lux IR on |
| Illumination Distance | 80 m (262.5 ft) |
| Illumination On/Off Control | Auto; manual |
| Illuminator Number | 2 |
| Pan/Tilt/Rotation Range | Pan: 0°–360° Tilt: 0°–180° Rotation: 0°–360° |
| Lens |
| Lens Type | Fixed-focal |
| Mount Type | M12 |
| Focal Length | 3.6 mm; 6 mm; 8 mm |
| Max. Aperture | F1.6 |
| Field of View | 3.6 mm: 109° × 92° × 48° (diagonal × horizontal × vertical) 6 mm: 65° × 57° × 30° (diagonal × horizontal × vertical) 8 mm: 48° × 43° × 24° (diagonal × horizontal × vertical) |
| Iris Type | Fixed iris |
| Close Focus Distance | 3.6 mm: 1.6 m (5.2 ft) 6 mm: 3.1 m (10.2 ft) 8 mm: 4.9 m (16.1 ft) |
| DORI Distance | Lens | Detect | Observe | Recognize | Identify |
| 3.6 mm | 80 m (262.5 ft) | 32 m (105.0 ft) | 16 m (52.5 ft) | 8 m (26.2 ft) |
| 6 mm | 120 m (393.7 ft) | 48 m (157.5 ft) | 24 m (78.7 ft) | 12 m (39.4 m) |
| | 8 mm | 150.4m (493.4 ft) | 60.2 m (197.5 ft) | 30.1 m (98.8 ft) | 15 m (49.2 ft) |
| Video |
| Frame Rate | CVI: PAL: 5M@25 fps; 4M@25 fps; 1080P@25 fps; NTSC: 5M@25 fps; 4M@30 fps; 1080P@30 fps AHD: PAL: 4M@25 fps; NTSC: 4M@30 fps TVI: PAL: 4M@25 fps; NTSC: 4M@30 fps CVBS: PAL: 960H; NTSC: 960H |
| Resolution | 5M (2880 × 1620); 4M (2560 × 1440); 1080P (1920 × 1080); 960 H (960 × 576/960 × 480) |
| Day/Night | Auto switch by ICR |
| BLC | BLC/HLC/DWDR |
| WDR | DWDR |
| White Balance | Auto; manual |
| Gain Control | Auto; manual |
| Noise Reduction | 2D NR |
| Smart IR | Yes |
| Mirror | Off/On |
| Privacy Masking | Off/On (8 area, rectangle) |
| Certifications |
| Certifications | CE (EN 55032:2015, EN 61000-3-2:2014, EN 61000-3-3:2013, EN 55024:2010+A1:2015, EN 55035:2017, EN 50130-4:2011+A1:2014, EN 62368-1:2014+A11:2017)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No.60950-1) |
| Port |
| Video Output | Video output choices of CVI/TVI/AHD/CVBS by one BNC port |
| Power |
| Power Supply | 12V ±30% DC |
| Power Consumption | Max 5.2W (12V DC, IR on) |
| Environment |
| Operating Temperature | -40°C to +60°C (-40°F to 140°F); <95% (non-condensation) |
| Storage Temperature | -40°C to +60°C (-40°F to 140°F); <95% (non-condensation) |
| Protection Grade | IP67 |
| Structure |
| Casing | Metal front cover+plastic main body+metal bracket |
| Camera Dimensions | 240.7 mm × 90.7 mm × 90.4 mm ( 9.48" × 3.57" × 3.56" ) |
| Net Weight | 0.41 kg (0.90 lb) |
| Gross Weight | 0.64 kg (1.41 lb) |
