Camera |
Image Sensor | 1/2.8" CMOS |
Max. Resolution | 1920 (H) × 1080 (V) |
Pixel | 2MP |
Scanning System | Progressive |
Electronic Shutter Speed | PAL: 1/25 s–1/100000 s NTSC: 1/30 s–1/100000 s |
S/N Ratio | >65 dB |
Min. Illumination | 0.001 Lux/F1.2, 30IRE, 0 Lux LED on |
Illumination Distance | 60 m (196.9 ft) |
Illuminator On/Off Control | Auto; manual |
Illuminator Number | 4 |
Pan/Tilt/Rotation Range | Pan: 0°–360° Tilt: 0°–90° Rotation: 0°–360° |
Lens |
Lens Type | Motorized vari-focal |
Auto Focus | Yes |
Mount Type | φ16 |
Focal Length | 2.7 mm–13.5 mm |
Max. Aperture | F1.2 |
Field of View | Diagonal: 39°–130° Horizontal: 34°–107° Vertical: 19°–56° |
Iris Type | Fixed iris |
Close Focus Distance | 1.5 m (4.9 ft) |
DORI Distance | Lens | Detect | Observe | Recognize | Identify |
2.7 mm | 44.9 m (147.3 ft) | 17.9 m (58.7 ft) | 8.9 m (29.2 ft) | 4.5 m (14.8 ft) |
13.5 mm | 128.6 m (421.9 ft) | 51.4 m (168.6 ft) | 25.7 m (84.3 ft) | 12.8 m (42 ft) |
Video |
Frame Rate | CVI: PAL: 1080p@25 fps; NTSC: 1080p@30 fps; AHD: PAL: 1080p@25 fps; NTSC: 1080p@30 fps; TVI: PAL: 1080p@25 fps; NTSC: 1080p@30 fps; CVBS: PAL: 960 × 576H; NTSC: 960 × 480H; |
Resolution | 1080P (1920 × 1080); 960H (960 × 576/960 × 480); |
BLC | BLC/WDR/HLC |
WDR | 130 dB |
White Balance | Auto; Area WB |
Gain Control | Auto; manual |
Noise Reduction | 3D NR |
Smart Light | Yes |
Mirror | Off/On |
Privacy Masking | Off/On (8 area, rectangle) |
Certifications |
Certifications | CE (EN55032, EN55024, EN50130-4) FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014) UL (UL60950-1+CAN/CSA C22.2 No.60950-1) |
Port |
Video Output | Video output choices of CVI/TVI/AHD/CVBS by one BNC port |
Audio Input | One channel built-in mic |
Power |
Power Supply | DC 12V ±30% |
Power Consumption | Max 10.2W (12V DC, LED on) |
Environment |
Operating Temperature | –30°C to +60°C (-22°F to 140°F);< 95% (non-condensation) |
Storage Temperature | –30°C to +60°C (-22°F to 140°F);< 95% (non-condensation) |
Protection Grade | IP67 |
Structure |
Casing | Metal throughout the whole casing |
Camera Dimensions | 244.1 mm × 90.4 mm × 90.4 mm (9.61" × 3.56" × 3.56") |
Net Weight | 0.79 kg (1.7 lb) |
Gross Weight | 1.07 kg (2.4 lb) |
