Camera |
Image Sensor | 1/2.7 inch CMOS |
Max. Resolution | 2880 (H) × 1620 (V) |
Pixel | 5MP |
Scanning System | Progressive |
Electronic Shutter Speed | PAL: 1/25s–1/100000s
NTSC: 1/30s–1/100000s |
S/N Ratio | >65 dB |
Min. Illumination | 0.005 Lux/F1.6, 30IRE, 0 Lux IR on |
Illumination Distance | 30 m (98.4 ft) |
Illuminator On/Off Control | Auto; manual |
Illuminator Number | 3 |
Pan/Tilt/Rotation Range | Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360° |
Lens |
Lens Type | Fixed-focal |
Mount Type | M12 |
Focal Length | 2.8 mm; 3.6 mm |
Max. Aperture | F1.6 |
Field of View | 2.8 mm: 132° × 111° × 58° (diagonal × horizontal × vertical) 3.6 mm: 109° × 92° × 48° (diagonal × horizontal × vertical) |
Iris Type | Fixed iris |
Close Focus Distance | 2.8 mm: 0.9 m (3.0 ft) 3.6 mm: 1.6 m (5.2 ft) |
DORI Distance | Lens | Detect | Observe | Recognize | Identify |
2.8 mm | 63.6 m (208.7 ft) | 25.4 m (83.3 ft) | 12.7 m (41.7 ft) | 6.4 m (21.0ft) |
3.6 mm | 80 m (262.5 ft) | 32 m (105.0 ft) | 16 m (52.5 ft) | 8 m (26.2 ft) |
Video |
Frame Rate | CVI: PAL: 5M@25 fps; 4M@25 fps; 1080P@25 fps; NTSC: 5M@25 fps; 4M@30 fps; 1080P@30 fps AHD: PAL: 4M@25 fps; NTSC: 4M@30 fps TVI: PAL: 4M@25 fps; NTSC: 4M@30 fps CVBS: PAL: 960H; NTSC: 960H |
Resolution | 5M (2880 × 1620); 4M (2560 × 1440); 1080P (1920 × 1080); 960 H (960 × 576/960 × 480) |
Day/Night | Auto switch by ICR |
BLC | BLC/HLC/DWDR |
WDR | DWDR |
White Balance | Auto; manual |
Gain Control | Auto; manual |
Noise Reduction | 2D NR |
Smart IR | Yes |
Mirror | Off/On |
Privacy Masking | Off/On (8 area, rectangle) |
Certifications |
Certifications | CE (EN 55032:2015, EN 61000-3-2:2014, EN 61000-3-3:2013, EN 55024:2010+A1:2015, EN 55035:2017, EN 50130-4:2011+A1:2014, EN 62368-1:2014+A11:2017)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No.60950-1) |
Port |
Audio Interface | One channel built-in mic (-A) |
Video Output | Video output choices of CVI/TVI/AHD/CVBS by one BNC port |
Power |
Power Supply | 12V ±30% DC |
Power Consumption | Max 3.7W (12V DC, IR on) |
Environment |
Operating Temperature | -40°C to +60°C (-40°F to 140°F); <95% (non-condensation) |
Storage Temperature | -40°C to +60°C (-40°F to 140°F); <95% (non-condensation) |
Protection Grade | IP67 |
Structure |
Casing | Plastic throughout the whole casing |
Camera Dimensions | 161.3mm×69.7mm×70.0mm(6.35"×2.75"×2.75" ) |
Net Weight | 0.19 kg (0.55 lb) |
Gross Weight | 0.29 kg (0.64 lb) |
