| Cámara |
| Sensor de imagen | Canal de visión general: CMOS de 1/2,8"; Canal de detalle: CMOS de 1/2,8" |
| Píxel | Canal de visión general: 8 MP; Canal de detalle: 4 MP |
| Máxima resolución | Canal de visión general: 5376 (H) × 1520 (V); Canal de detalle: 2560 (H) × 1440 (V) |
| memoria de sólo lectura | Canal de visión general: 4 GB; Canal de detalle: 4 GB |
| RAM | Canal de visión general: 2 GB; Canal de detalle: 1 GB |
| Velocidad de obturación electrónica | Canal de visión general: 1 s–1/100.000 s; Canal de detalle: 1 s–1/30.000 s |
| Sistema de escaneo | Progresivo |
| Iluminación mínima | Canal de visión general:
0,005 lux a F1,6 (color, 30 IRE);
0,0005 lux a F1,6 (blanco y negro, 30 IRE);
0 lux (iluminador activado)
Canal de detalle:
1 s–1/30 000 s
0,005 lux a F1,6 (color, 30 IRE);
0,0005 lux a F1,6 (blanco y negro, 30 IRE);
0 lux (iluminador activado) |
| Distancia de iluminación | Canal de visión general:
30 m (98,43 pies) (IR);
30 m (98,43 pies) (luz blanca)
Canal de detalle:
70 m (229,66 pies);
30 m (98,43 pies) (luz blanca) |
| Control de encendido y apagado del iluminador | Canal de descripción general: Manual; Automático; Desactivado
Canal de detalle: Prioridad de zoom; Manual; Automático; Desactivado |
| Número de iluminador | Canal de descripción general: 2 (luz infrarroja); 2 (luz blanca); Canal de detalle: 2 (fusión de luz dual); 2 (luz infrarroja) |
| Lente |
| Longitud focal | Canal de visión general: 2,8 mm; Canal de detalle: 4 mm–40 mm |
| Apertura máxima | Canal de visión general: F1.6; Canal de detalle: F1.6-F3.6 |
| Campo de visión | Canal de vista general: H: 180°; V: 47°;
Canal de detalle: H: 58°–11,3°; V: 33,1°–6,4°; D: 66,4°–12,8° |
| Zoom óptico | Canal de descripción general: NA; Canal de detalle: 10× |
| Control de enfoque | Automático; manual; semiautomático |
| Distancia de enfoque cercana | Canal de vista general: 0,6 m (1,97 pies); Canal de detalle: 0,1 m–0,5 m (0,33 pies–1,64 pies) |
| Iris Control | Canal de descripción general: NA; Canal de detalle: NA |
| Distancia DORI | Detectar | Observar | Reconocer | Identificar |
| 500 metros (1640,42 pies) | 197,5 metros (647,97 pies) | 100 metros (328,08 pies) | 50 metros (164,04 pies) |
| DORI (Detectar, Observar, Reconocer, Identificar) es un sistema estándar (EN-62676-4) que define la capacidad de una persona que visualiza el vídeo para distinguir personas u objetos dentro de un área cubierta. Los valores de esta tabla no reflejan las distancias de las funciones inteligentes. Para conocer las distancias de las funciones inteligentes, consulte el manual de instalación y puesta en marcha o la herramienta de diseño de proyectos. |
| PTZ | |
| Rango de panorámica/inclinación | Pan: 0° to 345°;
Tilt: -10° to +90° |
| Manual Control Speed | Overview channel: NA; Detail channel: H: 0.1°–80°/s; V: 0.1°–50°/s |
| Preset Speed | H: 80°/s; V: 50°/s |
| Preset | 300 |
| Tour | 8 (up to 32 presets per tour) |
| Power-off Memory | Yes |
| Idle Motion | Preset; Tour |
| Intelligence | |
| IVS (Perimeter Protection) | Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; human/vehicle alarm classification; linkage tracking (only for people) |
| Face Detection | Detail channel: Supports face detection, optimization, capturing pictures, uploading high-quality face snapshots and enhancing face images. Attribute Extraction is also supported, where 6 attributes and 8 expressions can be detected. Face cutout is also offered, where you can cutout one face at a time and customize the size to be a one-inch photo. The supported methods for capturing snapshots are real-time capturing, quality first, and selecting a preferred image among a group of snapshots. |
| Auto Tracking | Auto Tracking Lite |
| Smart Tracking | WizTracking: Xinghan large-scale AI models-driven human tracking Relay tracking: X-SPANS series only. Tracking continues after target exits overview channel until target leaves scene. Linkage tracking: X-SPANS series only. Tracks only targets visible in overview channel. |
| Auto Patrol | After an IVS alarm is triggered, it can link with up to 5 presets or scan to patrol the key areas. IVS can be enabled with SMD at the same time. |
| SMD | Yes |
| Acupick | Uses deep learning algorithms and works with backend devices to accurately match targets, such as people and motor vehicles, and search through live and recorded videos to quickly locate targets (Overview channel support) |
| Active Deterrence | |
| Light Warning | Red and blue light warning;
Flash duration: 5 s–30 s;
Flash frequency: high, medium, low |
| Sound Warning | Offers 11 sound alarm and 10 custom sound alarms can be imported.
Sound can be set from 0%–100%.
Play times can be set from 1-10. |
| Video | |
| Video Compression | H.264H; H.264B; Smart H.265+; H.265; Smart H.264+; H.264M; MJPEG (Sub Stream 1) |
| Streaming Capability | 3 streams |
| Resolution | Overview channel: 5376 × 1520; 26886 × 752; 1080p (1920 × 1080); 720p (1280 × 720); 1344 × 368; D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240);
Detail channel: 2560 × 1440; 3M (2304 × 1296); 1080p (1920 × 1080); 1280 × 960 (1.3M); 720p (1280 × 720); D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240) |
| Video Frame Rate | Overview channel: Main stream: 5376 × 1520 @(1–25/30 fps)
Sub stream 1: 1344 × 368/D1/VGA/CIF@ (1–25/30 fps)
Sub stream 2: 2688 × 752/1080p/1.3M/720p @(1–25/30 fps);
Detail channel: Main stream: 4M/3M/1080p/1.3M/720p @(1–25/30 fps)
Sub stream 1: D1/VGA/CIF@ (1–25/30 fps)
Sub stream 2: 1080p/1.3M/720p/ @(1–25/30 fps) |
| Bit Rate Control | CBR/VBR |
| Video Bit Rate | Overview channel: H264: 128 kbps–16,384 kbps
H265: 51 kbps–13,312 kbps;
Detail channel: H264: 96 kbps–16,384 kbps
H265: 38 kbps–10,240 kbps |
| Day/Night | Overview channel: Auto; Color; B/W;
Detail channel: Auto; Color; B/W; Electronic |
| BLC | Yes |
| WDR | Overview channel: DWDR
Detail channel: 120 dB |
| HLC | Yes |
| White Balance | Overview channel: Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp
Detail channel: Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp |
| Gain Control | Overview channel: Auto; manual; gain prio
Detail channel: Auto; manual; gain prio |
| Noise Reduction | Overview channel: 2D NR; 3D NR
Detail channel: 2D NR; 3D NR |
| Motion Detection | Yes |
| Region of Interest (RoI) | Yes |
| Image Stabilization | Overview channel: NA
Detail channel: Electronic Image Stabilization (EIS) |
| Defog | Overview channel: Electronic
Detail channel: Electronic |
| Digital Zoom | Overview channel: NA
Detail channel: 16× |
| Image Rotation | Overview channel: NA
Detail channel: 180° |
| S/N Ratio | Overview channel: ≥55dB
Detail channel: ≥55dB |
| Audio | |
| Audio Compression | Overview channel: PCM, G.711A, G.711Mu, G.726, MPEG2-Layer2, G.722.1, G.729;
Detail channel: NA |
| Privacy Masking | Up to 24 areas can be set, with up to 8 areas in the same view Multiple colors and mosaic available |
| Network | |
| Network Port | RJ-45 (100 Base-T) |
| Network Protocol | FTP; RTMP; IPv6; Bonjour; IPv4; DNS; RTCP; PPPoE; NTP; RTP; 802.1x; QoS; HTTPS; SNMP; TCP/IP; DDNS; UPnP; NFS; ICMP; UDP; IGMP; HTTP; SSL; DHCP; SMTP; RTSP; ARP |
| Interoperability | ONVIF (Profile S & Profile G & Profile T); CGI; SDK; P2P |
| Streaming Method | Unicast/Multicast |
| User/Host | 20 (total bandwidth: 64 M) |
| Storage | Micro SD card (512 GB); FTP/SFTP; NAS |
| Browser | web5.0:
IE 9 and later versions;
Chrome 41 and later versions;
Firefox 50 and later versions;
Safari 10 and later versions |
| Management Software | DMSS; DSS Pro |
| Mobile Client | iOS; Android |
| Certification | |
| Certifications | CE: EN55032/EN55035/IEC61000-3-2/IEC61000-3-3/EN62368-1/IEC62471 |
| Port | |
| Audio Input | 1 channel (LINE IN, bare wire,built-in mic (mutually exclusive)) |
| Audio Output | 1 channel (LINE OUT,bare wire;built-in speaker (mutually exclusive)) |
| Alarm Input | 1 (on-off value input: 0–5 VDC) |
| Alarm Output | 1 channel |
| Alarm Linkage | Capture; recording; send email; preset; alarm digital output; audio; warning light |
| Alarm Event | Motion/tampering detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection |
| Power | |
| Power Supply | 12 VDC, 3 A ± 10%
PoE+(802.3at) |
| Power Consumption | Básico: 12 W;
Máx: 25 W (iluminador + cristal calefactor + sirena y luz de disuasión activa + PTZ) |
| Ambiente | |
| Temperatura de funcionamiento | –30 °C a +60 °C (–22 °F a +140 °F) |
| Humedad de funcionamiento | ≤95% |
| Protección | TVS 6000 V a prueba de rayos; IP66; protección contra sobretensiones; protección contra transitorios de tensión |
| Estructura | |
| Dimensiones del producto | 140,3 mm × 181,7 mm × 238,8 mm (5,52" × 7,15" × 9,40") (largo × ancho × alto) |
| Peso neto | 2,17 kg (4,78 libras) |
| Peso bruto | 3,1 kg (6,83 libras) |
| La precisión de los ajustes preestablecidos para cámaras PTZ puede variar según la serie. Para escenas con altos requisitos de precisión, contacte con su representante de ventas local para obtener ayuda con la selección del modelo. |
