| Cámara |
| Sensor de imagen | CMOS de 1/2,8" |
| Píxel | 4 MP |
| Máxima resolución | 2560 (alto) × 1440 (vertical) |
| memoria de sólo lectura | 4 GB |
| RAM | 2 GB |
| Velocidad de obturación electrónica | 1 s–1/30000 s |
| Sistema de escaneo | Progresivo |
| Iluminación mínima | 0,005 lux a F1.6 (color, 30 IRE)
0,0005 lux a F1.6 (blanco y negro, 30 IRE)
0 lux (iluminador activado) |
| Distancia de iluminación | 100 m (328,08 pies) (luz cálida); 250 m (820,21 pies) (IR) |
| Control de encendido y apagado del iluminador | Zoom Prioritario; Manual; Automático; Desactivado |
| Número de iluminador | 6 (Fusión de luz dual) |
| Lente |
| Longitud focal | 3,95 mm–177,25 mm |
| Apertura máxima | F1.6–F4.95 |
| Campo de visión | Alto: 70,3°–1,8°; Oeste: 37°–1°; Profundidad: 69,3°–2° |
| Zoom óptico | 45× |
| Control de enfoque | Automático; Semiautomático; Manual |
| Distancia de enfoque cercana | 0,1 m–1 m (0,33 pies–3,28 pies) |
| Control del iris | Automático; Manual; Iris prior |
| Distancia DORI | | Lente | Detectar | Observar | Reconocer | Identificar | | O | 79,0 m
(259,19 pies) | 31,2 m
(102,38 pies) | 15,8 m
(51,84 pies) | 7,9 m
(25,92 pies) | | T | 3555,0 m
(11663,39 pies) | 1404,2 m
(4607,04 pies) | 711,0 m
(2332,68 pies) | 355,5 m
(1166,34 pies) | | *DORI (Detectar, Observar, Reconocer, Identificar) es un sistema estándar (EN-62676-4) que define la capacidad de una persona que ve el vídeo para distinguir personas u objetos dentro de un área cubierta. Los valores de esta tabla no reflejan las distancias de las funciones inteligentes. Para conocer las distancias de las funciones inteligentes, consulte el manual de instalación y puesta en marcha o la herramienta de diseño de proyectos. | |
| PTZ |
| Rango de panorámica/inclinación | Panorámica: 0° a 360° sin fin; Inclinación: –20° a +90°, giro automático 180° |
| Control manual de velocidad | Panorámica: 0°/s–260°/s; Inclinación: 0°/s–140°/s |
| Velocidad preestablecida | Panorámica: 300°/s; Inclinación: 200°/s |
| Programar | 300 |
| Recorrido | 8 |
| Patrón | 5 |
| Escanear | 5 |
| Memoria de apagado | Sí |
| Movimiento inactivo | Preajuste; Patrón; Recorrido; Escaneo |
| Protocolo PTZ | DH-SD
Pelco-P/D (reconocimiento automático) |
| Inteligencia |
| Metadatos de vídeo | Permite la detección de vehículos motorizados, vehículos no motorizados, rostros y cuerpos humanos, la optimización, la captura de imágenes y la carga de instantáneas faciales de alta calidad.
Extrae atributos de vehículos motorizados y no motorizados, detectando hasta 10 atributos para vehículos motorizados y 8 para vehículos no motorizados. También extrae atributos de rostros y cuerpos humanos, detectando hasta 6 atributos para rostros y 8 para cuerpos. |
| IVS (Perimeter Protection) | Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; human alarm classification; linkage tracking |
| Face Detection | Supports face detection, optimization, capturing pictures, uploading high-quality face snapshots and enhancing face images. Attribute extraction is also supported, where 6 attributes and 8 expressions can be detected. Face cutout is also offered, where you can cutout one face at a time and customize the size to be a one-inch photo. The supported methods for capturing snapshots are real-time capturing, quality first, and selecting a preferred image among a group of snapshots. |
| Construction Monitoring | Detects 6 helmet colors: Red, orange, yellow, blue, white, and black. An alarm will be triggered when a person is not wearing a helmet or when the color of the helmet that they are wearing does not match the configured color. It also supports compliance detection for work uniforms. Up to 5 work uniform sample libraries can be uploaded, which together can contain up to 1,000 images (the images must be 1080p and in the JPG format). An alarm will be triggered when the similarity between the detected work uniform and the samples in the library is below the set threshold (that is, below the minimum compliance standard for work uniforms). The system supports detecting the attributes of work uniforms such as the color of the uniform, and whether or not the person is wearing a mask and wearing shoe covers. An alarm will be triggered when the target is detected as not meeting the set requirements. It also detects and triggers alarms when only one person is in the construction site, and when no one is present in the detection area such as when a worker leaves their post or an area is left unmanned. |
| Smart Tracking | WizTracking |
| SMD | SMD 4.0 |
| AcuPick | Uses deep learning algorithms and works with backend devices to accurately match targets, such as people and motor vehicles, and search through live and recorded videos to quickly locate targets |
| Auto Patrol | After an IVS event occurs, the PTZ camera immediately initiates automated patrol of predefined key points to quickly cover potential risk areas and detect unknown threats in real time. |
| Active Deterrence |
| Light Warning | Red and blue warning light
Flash duration: 5 s–30 s
Flash frequency: high, medium, low |
| Sound Warning | Built in 11 voice alarm contents, supporting custom import of 10 voice contents; Sound: 0-100 adjustable; The playback frequency can be adjusted from 1 to 10 times; (requires external speaker for use) |
| Video |
| Video Compression | Smart H.265+;H.265;Smart H.264+;H.264;H.264B;H.264H;MJPEG(Sub Stream 1) |
| Streaming Capability | 3 streams |
| Resolution | 4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 960p (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA（640 × 480); CIF (352 × 288/352 × 240) |
| Video Frame Rate | Main stream: 4M/1080p/1.3M/720p@(1–25/30 fps)
Sub stream 1: D1/VGA/CIF@(1–25/30 fps)
Sub stream 2: 1080p/1.3M/720p/@(1–25/30 fps) |
| Bit Rate Control | CBR/VBR |
| Video Bit Rate | H264: 96 kbps–15104 kbps
H265: 38 kbps–9216 kbps |
| Day/Night | Auto (ICR)/Color/B/W |
| BLC | Yes |
| WDR | 120 dB |
| HLC | Yes |
| White Balance | Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp |
| Gain Control | Auto; manual; gain prio |
| Noise Reduction | 2D NR; 3D NR |
| Motion Detection | Yes |
| Region of Interest (RoI) | Yes |
| Image Stabilization | Electronic Image Stabilization (EIS) |
| Defog | Electronic |
| Digital Zoom | 16x |
| Image Rotation | 180° |
| Privacy Masking | Up to 24 areas can be set, with up to 8 areas in the same view
Multiple colors and mosaic available |
| S/N Ratio | ≥55 dB |
| Audio |
| Audio Compression | PCM; G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; G729; G723 |
| Built-in Speaker | Yes |
| Network |
| Network Port | RJ-45 (10/100 Base-T) |
| Network Protocol | HTTP;HTTPS;TCP/IP;IPv4;RTSP;UDP;SMTP;NTP;DHCP;DNS;DDNS;IPv6;802.1x;SSL;QoS;FTP;UPnP;ICMP;SNMP;IGMP;ARP;RTCP;RTP;PPPoE;RTMP;Bonjour;SMB;NFS |
| Interoperability | ONVIF (Profile S & Profile G & Profile T);CGI;SDK |
| Streaming Method | Unicast/Multicast |
| User/Host | 20 (total bandwidth: 64 M) |
| Storage | Micro SD card (512 GB); FTP/SFTP; NAS |
| Browser | IE 9 and later versions
Chrome 41 and later versions
Firefox 50 and later versions
Safari 10 and later versions |
| Management Software | DMSS;DSS Pro |
| Mobile Client | iOS;Android |
| Certification |
| Certifications | CE:EN55035;EN IEC61000-3-2;EN55032;EN60950;EN62368-1 |
| Port |
| RS-485 | 1 (Bit range: 1200 bps–9600 bps) |
| Audio Input | 1 channel (LINE IN, bare wire,built-in mic (mutually exclusive)） |
| Audio Output | 1 channel (LINE OUT,bare wire;built-in speaker (mutually exclusive)） |
| Alarm Input | 7 (on-off value input: 0–5 VDC) |
| Alarm Output | 2 channels |
| Alarm Linkage | Capture; recording; send email; preset; tour; pattern; alarm digital output; audio |
| Alarm Event | Motion/tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection |
| Power |
| Power Supply | 24 VDC, 2.5 A ± 25%
PoE+ (802.3at) |
| Power Consumption | Basic: 12 W
Max. (WDR + IR on + PTZ operation + Alarm): 21 W (24 VDC) |
| Power Adapter | Included |
| Environment |
| Operating Temperature | –40 °C to +70 °C (–40 °F to +158 °F) |
| Operating Humidity | ≤95% |
| Protection | IP67;IK10;TVS 6000 V lightning proof; surge protection; voltage transient protection |
| Structure |
| Product Dimensions | 208 mm × 202 mm × 325 mm (8.19" × 7.95" × 12.8") (L × W × H) |
| Net Weight | 4.45 kg (9.81 lb) |
| Gross Weight | 6.62 kg (14.59 lb) |
