| Cámara |
| Sensor de imagen | CMOS de 1/2,7" |
| Máxima resolución | 3840 (alto) × 2160 (vertical) |
| memoria de sólo lectura | 128 MB |
| RAM | 256 MB |
| Sistema de escaneo | Progresivo |
| Velocidad de obturación electrónica | Automático/Manual 1/3 s–1/100.000 s |
| Iluminación mínima | 0,009 lux a F2.0 (color, 30 IRE)
0,0009 lux a F2.0 (blanco y negro, 30 IRE)
0 lux (iluminador activado) |
| Relación señal/ruido | >56 dB |
| Distancia de iluminación | 30 m (98,43 pies) (IR) |
| Control de encendido y apagado del iluminador | Auto; Manual |
| Número de iluminador | 1 (LED infrarrojo) |
| Rango de giro/inclinación/rotación | Panorámica: 0°–360°
Inclinación: 0°–90°
Rotación: 0°–360° |
| Lente |
| Tipo de lente | Focal fijo |
| Montura de lente | M12 |
| Longitud focal | 2,8 mm; 3,6 mm |
| Apertura máxima | F2.0 |
| Campo de visión | 2,8 mm: Alto: 106°; V: 56°; Fondo: 125°
3,6 mm: Alto: 88°; V: 46°; Re: 104° |
| Iris Control | Fijado |
| Distancia de enfoque cercana | 2,8 mm: 1,3 m (4,27 pies)
3,6 mm: 1,9 m (6,23 pies ) |
| Distancia DORI | Lente | Detectar | Observar | Reconocer | Identificar |
| 2,8 milímetros | 88,0 metros (288,71 pies) | 35,2 metros (115,49 pies) | 17,6 metros (57,74 pies) | 8,8 metros (28,87 pies) |
| 3,6 milímetros | 106,7 metros (350,07 pies) | 42,7 metros (140,09 pies) | 21,3 metros (69,88 pies) | 10,7 metros (35,10 pies) |
| Inteligencia |
| IVS (Protección Perimetral) | Intrusión, cable trampa (las dos funciones respaldan la clasificación y la detección precisa de vehículos y personas) |
| Búsqueda inteligente | Trabaje en conjunto con Smart NVR para realizar búsquedas inteligentes refinadas, extracción de eventos y fusión con videos de eventos. |
| Video |
| Compresión de vídeo | H.265; H.264; H.264H; H.264B; MJPEG (solo compatible con la transmisión secundaria) |
| Códec inteligente | H.265+ inteligente; H.264+ inteligente |
| Velocidad de fotogramas del vídeo | Main stream: 3840 × 2160@(1–20 fps)/2688 × 1520@(1–25/30 fps)
sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. |
| Stream Capability | 2 streams |
| Resolution | 3840 × 2160 (3840 × 2160); 3072 × 2048 (3072 × 2048); 3072 ×1728 (3072 × 1728); 2880 × 1620 (2880 × 1620); 2688 × 1520 (2688 × 1520); 3M (2048 × 1536); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
| Bit Rate Control | CBR/VBR |
| Video Bit Rate | H.264: 32 kbps–8192 kbps
H.265: 12 kbps–8192 kbps |
| Day/Night | Auto(ICR)/Color/B/W |
| BLC | Yes |
| HLC | Yes |
| WDR | 120 dB |
| White Balance | Auto; natural; street lamp; outdoor; manual; regional custom |
| Gain Control | Auto; Manual |
| Noise Reduction | 3D NR |
| Motion Detection | OFF/ON (4 areas, rectangular) |
| Region of Interest (RoI) | Yes (4 areas) |
| Smart Illumination | Yes |
| Image Rotation | 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower) |
| Mirror | Yes |
| Privacy Masking | 4 areas |
| Audio |
| Built-in MIC | Yes |
| Audio Compression | G.711a; G.711Mu; PCM; G.726 |
| Alarm |
| Alarm Event | No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; audio detection; voltage detection; SMD; security exception |
| Network |
| Network Port | RJ-45 (10/100 Base-T) |
| SDK and API | Yes |
| Network Protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; Boujour |
| Interoperability | ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone |
| User/Host | 20 (Total bandwidth: 48 M) |
| Storage | FTP; SFTP; Micro SD card (support max. 256 GB); NAS |
| Browser | IE
Chrome
Firefox |
| Management Software | Smart PSS; DSS; DMSS |
| Mobile Client | iOS; Android |
| Cyber Security | Configuration encryption; trusted execution; Digest; security logs; WSSE; account lockout; syslog; video encryption; 802.1x; IP/MAC filtering; HTTPS; trusted upgrade; trusted boot; firmware encryption; generation and importing of X.509 certification |
| Certification |
| Certifications | CE-LVD: EN62368-1;
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU;
FCC: 47 CFR FCC Part 15, Subpart B;
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07 |
| Power |
| Power Supply | 12 VDC/PoE (802.3af) |
| Power Consumption | Basic: 2.7 W (12 VDC); 3.4 W (PoE)
Max. (H.265+ max. resolution + max. stream+ WDR + IR intensity + IVS): 4.5 W (12 VDC); 5.4 W (PoE) |
| Environment |
| Operating Temperature | –40 °C to +60 °C (–40 °F to +140 °F) |
| Operating Humidity | ≤95% |
| Storage Temperature | –40 °C to +60 °C (–40 °F to +140 °F) |
| Storage Humidity | ≤95% |
| Protection | IP67 |
| Structure |
| Casing Material | Metal |
| Product Dimensions | 166.2 mm × 70 mm × 70 mm (6.54" × 2.76" × 2.76") (L × W × H) |
| Net Weight | 0.48 kg (1.06 lb) |
| Gross Weight | 0.59 kg (1.30 lb) |
