| Cámara |
| Sensor de imagen | CMOS de 1/1,8" |
| Máxima resolución | 2688 (alto) × 1520 (vertical) |
| memoria de sólo lectura | 128 MB |
| MARCO | 256 MB |
| Sistema de escaneo | Progresivo |
| Velocidad de obturación electrónica | Automático/Manual 1/3 s–1/100 000 s |
| Iluminación mínima | 0,0005 lux a F1.0 |
| Relación señal/ruido | >56 dB |
| Distancia de iluminación | Hasta 50 m (164,04 pies) (luz cálida) |
| Control de encendido y apagado del iluminador | Automático; Manual |
| Número de iluminador | 4 (Luz cálida) |
| Lente |
| Tipo de lente | Focal fijo |
| Montura de lente | M16 |
| Longitud focal | 3,6 mm; 6 mm |
| Apertura máxima | F1.0 |
| Campo de visión | 3,6 mm: Alto: 94°; Alto: 50°; Profundidad: 113° 6 mm: Alto: 58°; Alto: 31°; Fondo: 67° |
| Control del iris | Fijado |
| Distancia de enfoque cercana | 3,6 mm: 2,6 m (8,53 pies) 6 mm: 5,4 m (17,72 pies) |
| Distancia DORI | Lente | Detectar | Mirar | Reconocimiento | Identificar |
| 3,6 milímetros | 70,3 m (230,64 pies) | 28,1 metros (92,19 pies) | 14,1 metros (46,26 pies) | 7,0 metros (22,97 pies) |
| 6 milímetros | 116,6 metros (382,55 pies) | 46,6 metros (152,89 pies) | 23,3 metros (76,44 pies) | 11,7 metros (38,39 pies) |
| DORI (Detectar, Observar, Reconocer, Identificar) es un sistema estándar (EN-62676-4) que define la capacidad de una persona que visualiza el vídeo para distinguir personas u objetos dentro de un área cubierta. Los valores de esta tabla no reflejan las distancias de las funciones inteligentes. Para conocer las distancias de las funciones inteligentes, consulte el manual de instalación y puesta en marcha o la herramienta de diseño de proyectos. |
| Inteligencia |
| IVS (Protección Perimetral) | Intrusión, cable trampa (las dos funciones respaldan la clasificación y la detección precisa de vehículos y personas) |
| SMD | SMD Plus |
| Búsqueda inteligente | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos |
| Video |
| Video Compression | H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) |
| Smart Codec | Smart H.265+; Smart H.264+ |
| Video Frame Rate | Main stream: 2688 × 1520@(1–20 fps)/2560 × 1440@(1–25/30 fps) sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps) *The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. |
| Stream Capability | 2 streams |
| Resolution | 4M (2688 × 1520/2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
| Bit Rate Control | VBR;CBR |
| Video Bit Rate | H.264: 32 kbps–6144 kbps; H.265: 12 kbps–6144 kbps |
| Day/Night | Color/B/W |
| BLC | Yes |
| HLC | Yes |
| WDR | 120 dB |
| White Balance | Auto; natural; street lamp; outdoor; manual; regional custom |
| Gain Control | Auto/Manual |
| Noise Reduction | 3D NR |
| Motion Detection | OFF/ON (4 areas, rectangular) |
| Region of Interest (RoI) | Yes (4 areas) |
| Smart Illumination | Yes |
| Image Rotation | 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower) |
| Mirror | Yes |
| Privacy Masking | 4 areas |
| LDC | Yes |
| Audio |
| Built-in MIC | Yes, built-in Mic |
| Audio Compression | G.711a; G.711Mu; PCM; G.726 |
| Alarm |
| Alarm Event | No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; audio detection; voltage detection; SMD; security exception |
| Network |
| Network Port | RJ-45 (10/100 Base-T) |
| SDK and API | Yes |
| Network Protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; P2P; Bonjour; Auto Registration |
| Interoperability | ONVIF (Profile S & Profile G & Profile T); CGI |
| User/Host | 20 (Total bandwidth: 48 M) |
| Storage | FTP; SFTP; Micro SD card (support max. 256 GB); NAS |
| Browser | IE; Chrome; Firefox |
| Management Software | Smart PSS Lite; DSS; DMSS |
| Mobile Client | iOS;Android |
| Cyber Security | Video encryption;Firmware encryption;Configuration encryption;Digest;WSSE;Account lockout;Security logs;IP/MAC filtering;Generation and importing of X.509 certification;syslog;HTTPS;802.1x;Trusted boot;Trusted execution;Trusted upgrade;Session security;Security warning |
| Certification |
| Certifications | CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU |
| Power |
| Power Supply | 12 VDC; PoE |
| Power Consumption | Basic: 2.0 W (12 VDC); 2.5 W (PoE); Max.: 5.7 W (12 VDC); 6.8 W (PoE) (H.265+ intelligence on + WDR + illuminator intensity) |
| Environment |
| Operating Temperature | –40 °C to +60 °C (–40 °F to +140 °F) |
| Operating Humidity | ≤95% (RH), non-condensing |
| Storage Temperature | –40 °C to +60 °C (–40 °F to +140 °F) |
| Storage Humidity | ≤95% (RH), non-condensing |
| Protection | IP67 |
| Structure |
| Casing Material | Metal + plastic |
| Product Dimensions | 201.0 mm × 103.8 mm × 97.8 mm (7.91" × 4.09" × 3.85") (L × W × H) |
| Net Weight | 0.68 kg (1.50 lb) |
| Gross Weight | 1.27 kg (2.80 lb) |
