Camera
|
Image Sensor
|
1/2.8” 2Megapixel progressive scan STARVIS™ CMOS
|
Effective Pixels
|
1920 (H) × 1080 (V)
|
RAM/ROM
|
512 MB/128 MB
|
Scanning System
|
Progressive
|
Electronic Shutter Speed
|
Auto/Manual, 1/3 s–1/100000 s
|
Minimum Illumination
|
0.002 Lux@F1.5
|
IR Distance
|
Distance up to 150 m (492 ft)
|
IR On/Off Control
|
Auto/Manual
|
IR LEDs
|
4
|
Lens
|
Lens Type
|
Motorized vari-focal
|
Mount Type
|
Board-in
|
Focal Length
|
5.3 mm–64.0 mm
|
Max. Aperture
|
F1.5
|
Angle of View
|
H: 58°–4°, V: 34°–2°
|
Aperture Type
|
Auto (HALL)
|
Close Focus Distance
|
1.0 m–1.5 m (3.28 ft–4.92 ft)
|
DORI Distance
|
Lens
|
Detect
|
Observe
|
Recognize
|
Identify
|
W
|
73m(240ft)
|
29m(95ft)
|
15m(49ft)
|
7m(23ft)
|
T
|
883m(2897ft)
|
353m(1158ft)
|
177m(580ft)
|
88m(289ft)
|
Pan/Tilt/Rotation
|
Pan/Tilt/Rotation Range
|
Pan: 0˚–360˚; Tilt: 0˚–90˚; Rotation: 0˚–360˚
|
Artificial Intelligence
|
Face Detection
|
Support face image capture
|
Face Attributes
|
Support 6 kinds of face attributes extraction: Age, Gender,Expression (Jolly, Surprise, Normal, Rage, Sad, Disgusted, Confused, Frightened), Glasses, Mouth Mask, Moustache & Beard
|
Perimeter Protection
|
Tripwire, intrusion (Recognition of vehicle and people), fast moving, loitering detection, parking detection and people gathering
|
People Counting
|
Support Line crossing/Region/Queueing people counting; Support 4 accesses independent detection, 4 areas independent detection
|
General Intelligence
|
Event Trigger
|
Motion detection, Video tampering , Scene changing, Network disconnection , IP address conflict, Illegal Access, Storage anomaly
|
General Intelligence
|
Object Abandoned/Missing
|
Heat Map
|
Yes
|
Video
|
Compression
|
H.265,H.264,H.264B,H.264H,
MJPEG (sub stream)
|
