| Cámara |
| Sensor de imagen | CMOS de 1/2,9" |
| Máxima resolución | 2688 (alto) × 1520 (vertical) |
| memoria de sólo lectura | 128 MB |
| RAM | 128 MB |
| Sistema de escaneo | Progresivo |
| Velocidad de obturación electrónica | Automático/Manual 1/3 s–1/100.000 s |
| Iluminación mínima | 0,006 lux a F1,5 (color, 30 IRE) 0,0006 lux a F1,5 (blanco y negro, 30 IRE) 0 lux (iluminador encendido) |
| Relación señal/ruido | > 56 dB |
| Distancia de iluminación | Hasta 60 m (196,85 pies) (LED IR) |
| Control de encendido y apagado del iluminador | Automático; Manual |
| Número de iluminador | 4 (LED infrarrojo) |
| Rango de giro/inclinación/rotación | Panorámica: 0°–360°
Inclinación: 0°–90°
Rotación: 0°–360° |
| Lente |
| Tipo de lente | varifocal motorizado |
| Montura de lente | φ14 |
| Longitud focal | 2,7 mm–13,5 mm |
| Apertura máxima | F1.5 |
| Campo de visión | Alto: 104°–29°;
Oeste: 54°–16°;
Profundidad: 125°–34° |
| Control del iris | Fijado |
| Distancia de enfoque cercana | 0,8 m (2,62 pies) |
| Distancia DORI | Lente | Detectar | Observar | Reconocer | Identificar |
| O | 64,0 m (209,97 pies) | 25,6 metros (83,99 pies) | 12,8 metros (41,99 pies) | 6,4 metros (20,99 pies) |
| T | 210,0 m (688,97 pies) | 84,0 metros (275,59 pies) | 42,0 metros (137,80 pies) | 21,0 metros (68,90 pies) |
| DORI (Detectar, Observar, Reconocer, Identificar) es un sistema estándar (EN-62676-4) que define la capacidad de una persona que visualiza el vídeo para distinguir personas u objetos dentro de un área cubierta. Los valores de esta tabla no reflejan las distancias de las funciones inteligentes. Para conocer las distancias de las funciones inteligentes, consulte el manual de instalación y puesta en marcha o la herramienta de diseño de proyectos. |
| Inteligencia |
| IVS (Perimeter Protection) | Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human) |
| Smart Search | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos |
| Video |
| Video Compression | H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) |
| Smart Codec | Smart H.265+; Smart H.264+ |
| Video Frame Rate | Main stream: 2688 × 1520@(1–20 fps)/2560 × 1440@(1-25/30 fps)
Sub stream: 704 × 576@(1–25 fps)/704 × 480@(1–30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. |
| Stream Capability | 2 streams |
| Resolution | 2688 × 1520 (2688 × 1520); 2560 × 1440 (2560 × 1440); 2304 × 1296 (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
| Bit Rate Control | CBR/VBR |
| Video Bit Rate | H.264: 32 kbps–6144 kbps;
H.265: 12 kbps–6144 kbps |
| Day/Night | Auto(ICR)/Color/B/W |
| BLC | Yes |
| HLC | Yes |
| WDR | 120 dB |
| White Balance | Auto; natural; street lamp; outdoor; manual; regional custom |
| Gain Control | Manual;Auto |
| Noise Reduction | 3D NR |
| Motion Detection | OFF/ON (4 areas, rectangular) |
| Region of Interest (RoI) | Yes (4 areas) |
| Smart Illumination | Yes |
| Image Rotation | 0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower) |
| Mirror | Yes |
| Privacy Masking | 4 areas |
| Audio |
| Built-in MIC | Yes |
| Audio Compression | G.711a; G.711Mu; G.726; PCM |
| Alarm |
| Alarm Event | No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; audio detection; voltage detection; defocus detection; external alarm (Only - ZAS supports); SMD; security exception |
| Network |
| Network Port | RJ-45 (10/100 Base-T) |
| SDK and API | Yes |
| Network Protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP; P2P |
| Interoperability | ONVIF (Profile S/Profile G/Profile T); CGI |
| User/Host | 6 (Total bandwidth: 36 M) |
| Storage | FTP; SFTP; Micro SD card (support max. 256 GB) |
| Browser | IE
Chrome
Firefox |
| Management Software | SmartPSS Lite; DSS; DMSS |
| Mobile Client | iOS; Android |
| Cyber Security | Video encryption; Configuration encryption; Digest; WSSE; Account lockout; Security logs; IP/MAC filtering; Generation and importing of X.509 certification; syslog; HTTPS; 802.1x; Trusted boot; Trusted execution; Trusted upgrade |
| Certification |
| Certifications | CE-LVD: EN62368-1; CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU; FCC: 47 CFR FCC Part 15, Subpart B; UL/CUL: UL62368-1 & CAN/CSA C22.2 No. 62368-1-14 |
| Port |
| Audio Input | 1 channel (RCA port) (Only - ZAS supports) |
| Audio Output | 1 channel (RCA port) (Only - ZAS supports) |
| Alarm Input | 1 channel in: 5mA 3V–5V DC (Only - ZAS supports) |
| Alarm Output | 1 channel out: 300mA 12V DC (Only - ZAS supports) |
| Power |
| Power Supply | 12 VDC/PoE (802.3af) |
| Consumo de energía | -ZS:
Básica: 2,4 W (12 VCC); 3,1 W (PoE)
Máx. (H.265+inteligencia activada + WDR + IR activado): 8,7 W (12 VCC); 10,1 W (PoE)
-ZAS:
Básica: 2,4 W (12 VCC); 3,1 W (PoE)
Máx. (H.265+inteligencia activada + WDR + IR activado): 8,8 W (12 VCC); 10,2 W (PoE) |
| Ambiente |
| Temperatura de funcionamiento | –30 °C a +60 °C (–22 °F a +140 °F) |
| Humedad de funcionamiento | ≤95% |
| Temperatura de almacenamiento | –40 °C a +60 °C (–40 °F a +140 °F) |
| Protección | IP67, IK10 (opcional) |
| Estructura |
| Material de la carcasa | Metal |
| Dimensiones del producto | 238,5 mm × 90,7 mm × 90,7 mm (9,39" × 3,57" × 3,57") (largo × ancho × alto) |
| Peso neto | -ZS: 0,73 kg (1,6 libras)
-ZAS: 0,76 kg (1,7 libras) |
| Peso bruto | -ZS: 0,99 kg (2,2 libras)
-ZAS: 1,02 kg (2,2 libras) |
