Cámara
|
|
Sensor de imagen
|
1 / 2.7 "CMOS progresivo de 5 megapíxeles
|
|
Píxeles efectivos
|
2592 (H) × 1944 (V)
|
|
ROM
|
128 MB
|
|
RAM
|
512 MB
|
|
Sistema de escaneo
|
Progresivo
|
|
Velocidad de obturación electrónica
|
Auto / Manual 1/3 s – 1/100000 s
|
|
Min. Iluminación
|
0.005 Lux@F1.6
|
|
Distancia IR
|
50 m (164,0 pies)
|
|
Control de encendido / apagado IR
|
Manual de auto
|
|
Número de LED IR
|
3 (LED IR)
|
|
Pan / Tilt / Rango de rotación
|
Horizontal: 0 ° –355 °; vertical: 0 ° –65 °; rotación: 0 ° –355 °
|
|
Lente
|
|
Tipo de lente
|
Focal fijo
|
|
Tipo de montaje
|
M12
|
|
Longitud focal
|
2,8 mm
|
|
Max. Abertura
|
F1.6
|
|
Campo de visión
|
2,8 mm: horizontal: 98 °; vertical: 72 °; diagonal: 130 °
|
|
Tipo de iris
|
Apertura fija
|
|
Distancia de enfoque cercana
|
2,8 mm: 0,9 m (3,0 pies)
|
|
DORI Distancia
|
Lente
|
Detectar
|
Observar
|
Reconocer
|
Identificar
|
|
2.8mm
|
56,0 m
(183,7 pies)
|
22,4 m
(73,5 pies)
|
11,2 m
(36.8 pies)
|
5,6 m
(18,4 pies)
|
|
|
|
|
|
|
|
|
|
|
|
|
|
Profesional, inteligente
|
|
Protección perimetral
|
Tripwire intrusión (Reconocimiento de humanos y vehículos)
|
|
Búsqueda inteligente
|
Trabaje junto con Smart NVR para realizar búsquedas inteligentes refinadas, extracción de eventos y fusión a videos de eventos
|
|
Vídeo
|
|
Compresión de video
|
H.265; H.264; H.264H; H.264B; MJPEG
|
|
Códec inteligente
|
si
|
|
Velocidad de fotogramas de vídeo
|
Transmisión principal (2592 × 1944 @ 1–20 fps)
(2688 × 1520 @ 1–25 / 30 fps)
transmisión secundaria (704 × 576 @ 1–25 / 30 fps)
tercera transmisión (1280 × 720 @ 1–25 / 30 fps)
|
|
Stream Capability
|
3 streams
|
|
Resolution
|
5M (2592 × 1944); 4M (2688 × 1520); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
|
|
Bit Rate Control
|
CBR/VBR
|
|
Video Bit Rate
|
H.264: 3 Kbps–8192 Kbps
H.265: 3 Kbps–8192 Kbps
|
|
Day/Night
|
Auto(ICR)/Color/B/W
|
|
BLC
|
Yes
|
|
HLC
|
Yes
|
|
WDR
|
120 dB
|
|
White Balance
|
Auto/natural/street lamp/outdoor/manual/regional custom
|
|
Gain Control
|
Auto/Manual
|
|
Noise Reduction
|
3D DNR
|
|
Motion Detection
|
OFF/ON (4 areas, rectangular)
|
|
Region of Interest(RoI)
|
Yes (4 areas)
|
|
Smart IR
|
Yes
|
|
Image Rotation
|
0°/90°/180°/270° (Support 90°/270° with 1920 × 1080 resolution.)
|
|
Mirror
|
Yes
|
|
Privacy Masking
|
4 areas
|
|
Network
|
|
Network
|
RJ-45 (10/100 Base-T)
|
|
Protocol
|
IPv4;IPv6;HTTP;HTTPS;TCP;UDP;ARP;RTP;RTSP;RTCP;
RTMP;SMTP;FTP;SFTP;DHCP;DNS;DDNS;QoS;UPnP;NTP;Multicast;ICMP;IGMP;NFS;PPPoE;802.1x;SNMP
|
|
Interoperability
|
ONVIF(Profile S/Profile G);CGI;P2P;Milestone;Genetec
|
|
Scene Self-adaptation
|
Yes
|
|
User/Host
|
20 (Total bandwidth: 64 M)
|
|
Edge Storage
|
FTP; SFTP; Micro SD Card (support max. 256 G);Cloud; NAS
|
|
Browser
|
IE: IE8, IE9, IE11
Chrome
Firefox
|
|
Management Software
|
Smart PSS, DSS, DMSS
|
|
Mobile Phone
|
IOS; Android
|
|
Certification
|
|
Certifications
|
CE-LVD: EN60950-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07
|
|
Power
|
|
Power Supply
|
12V DC/PoE (802.3af)
|
|
Power Consumption
|
<7.3W
|
|
Environment
|
|
Operating Conditions
|
-40°C to +60°C (-40°F to +140°F)/less than≤95%
|
|
Strorage Conditions
|
-40°C to +60°C (-40°F to +140°F)
|
|
Ingress Protection
|
IP67; IK10
|
|
Structure
|
|
Casing
|
Metal
|
|
Dimensions
|
81 mm × Φ109.9 mm (3.2" × Φ4.3")
|
|
Net Weight
|
378 g (0.8 lb)
|
|
Gross Weight
|
523 g (1.2 lb)
|
