| Cámara |
| Sensor de imagen | CMOS de 1/1,8" |
| Máxima resolución | 2688 (alto) × 1520 (vertical) |
| memoria de sólo lectura | 4 GB |
| RAM | 1 GB |
| Sistema de escaneo | Progresivo |
| Velocidad de obturación electrónica | Automático/Manual 1/3 s–1/100.000 s |
| Iluminación mínima | 0,0006 lux a F1.2 (color, 30 IRE)
0,0003 lux a F1.2 (blanco y negro, 30 IRE)
0 lux (iluminador activado) |
| Relación señal/ruido | > 56 dB |
| Distancia de iluminación | Hasta 40 m (131,23 pies) (IR) |
| Control de encendido y apagado del iluminador | Auto; Zoomprio; Manual |
| Número de iluminador | 3 (LED infrarrojo) |
| Ajuste del ángulo | Panorámica: 0°–355°
Inclinación: 0°–80°
Rotación: 0°–355° |
| Lente |
| Tipo de lente | varifocal motorizado |
| Montura de lente | φ14 |
| Longitud focal | 2,7 mm–12,0 mm |
| Apertura máxima | F1.2 |
| Campo de visión | Alto: 114°–48°; Oeste: 59°–27°; Profundidad: 143°–56° |
| Iris Control | Auto |
| Tipo de control del iris | P-Iris |
| Distancia de enfoque cercana | 1,75 m (5,74 pies) |
| Distancia DORI | Lente | Detectar | Observar | Reconocer | Identificar |
| EN | 60,4 m (198,16 pies) | 24,2 metros (79,40 pies) | 12,1 metros (39,70 pies) | 6,0 metros (19,69 pies) |
| T | 128,7 m (425,52 pies) | 51,5 metros (168,96 pies) | 25,7 metros (84,32 pies) | 12,9 metros (42,32 pies) |
| DORI (Detectar, Observar, Reconocer, Identificar) es un sistema estándar (EN-62676-4) que define la capacidad de una persona que visualiza el vídeo para distinguir personas u objetos dentro de un área cubierta. Los valores de esta tabla no reflejan las distancias de las funciones inteligentes. Para conocer las distancias de las funciones inteligentes, consulte el manual de instalación y puesta en marcha o la herramienta de diseño de proyectos. |
| Inteligencia |
| IVS (Protección Perimetral) | Intrusión, cable trampa, movimiento rápido (las tres funciones permiten la clasificación y detección precisa de vehículos, animales y personas); detección de merodeo, aglomeración de personas y detección de estacionamiento. Compatible con modo de larga distancia. Autoaprendizaje: filtra falsas alarmas. |
| Detección inteligente de objetos | Smart abandoned object; smart missing object |
| SMD | SMD 3.0 |
| AcuPick | Uses deep learning algorithms and works with back-end devices to accurately match targets, such as people, animal,and motor vehicles, and search through live and recorded videos to quickly locate targets. |
| AI SSA | Yes |
| Face Detection | Face detection; track; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face attributes extraction including 6 attributes and 8 expressions; face snapshot set as face, one-inch photo or custom; snapshot strategies (real-time snapshot, quality priority and optimization snapshot); face angle filter; optimization time setting. |
| People Counting | Tripwire people counting, generating and exporting report (day/week/month/year); people counting in area and queue management, generating and exporting report (day/week/month); 4 rules can be set for tripwire, people counting in area and queue management. |
| Heat Map | Yes |
| Video Metadata | Motor vehicle, non-motor vehicle, face, human body detection; track; snapshot; snapshot optimization; optimal face snapshot upload.
Motor vehicle attributes: vehicle type, vehicle color, vehicle logo and other attributes : seatbelt, smoking, calling.
Non-motor vehicle attributes: type, color, number of people, top type and color, hat.
Human body attributes: gender, top/bottom type and color, bag, hat and umbrella.
Face attributes: gender, age, expressions, glasses, face mask and beard. |
| Smart Search | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos |
| Smart Sound Detection | Yes |
| Video |
| Video Compression | H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) |
| Smart Codec | Smart H.265+; Smart H.264+ |
| AI Coding | AI H.265; AI H.264 |
| Video Frame Rate | Main stream: 2688 × 1520 (1 fps–25/30 fps) /1920 × 1080 (1 fps–50/60 fps)
Sub stream: D1@(1–25/30 fps)
Third stream: 1080p@(1–25/30 fps)
Fourth stream: 720p@(1–25/30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. |
| Stream Capability | 4 streams |
| Resolution | 4M (2688 × 1520); 3.6M (2560 × 1440); 3M (2048 × 1536); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
| Bit Rate Control | CBR/VBR |
| Video Bit Rate | H.264: 32 kbps–16384 kbps; H.265: 12 kbps–11008 kbps |
| Day/Night | Auto(ICR)/Color/B/W |
| BLC | Yes |
| HLC | Yes |
| WDR | 140 dB |
| Scene Self-adaptation (SSA) | Yes |
| White Balance | Auto; natural; street lamp; outdoor; manual; regional custom |
| Gain Control | Auto |
| Noise Reduction | 3D NR |
| Motion Detection | OFF/ON (4 areas, rectangular) |
| Region of Interest (RoI) | Yes (4 areas) |
| Image Stabilization | Electronic Image Stabilization (EIS) |
| Smart Illumination | Yes |
| Defog | Yes |
| Image Rotation | 0°/90°/180°/270° (Support 90°/270° with 4M (2688 × 1520)resolution and lower) |
| Mirror | Yes |
| Privacy Masking | 8 areas |
| LDC | Yes |
| Audio |
| Built-in MIC | Yes, built-in dual Mic |
| Audio Compression | G.711a; G.711Mu; PCM; G.726; G.723 |
| Alarm |
| Alarm Event | No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; fast moving; abandoned object; missing object; loitering detection; people gathering; parking detection; scene changing; audio detection; voltage detection; external alarm; face detection; video metadata; SMD; people counting in area; stay detection; people counting; people number error detection; queue people number alarm; queue time alarm; security exception |
| Network |
| Network Port | RJ-45 (10/100 Enhancement Base-T) |
| SDK and API | Yes |
| Network Protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; P2P; Auto Register |
| Interoperability | ONVIF (Profile S/Profile G/Profile T/Profile M); CGI |
| User/Host | 20 (Total bandwidth: 80 M) |
| Storage | FTP; SFTP; Micro SD card (support max. 1 TB); NAS |
| Browser | IE: IE 9 and later
Chrome: Chrome 102 and later
Firefox: Firefox 88 and later |
| Management Software | SmartPSS Lite; DSS; DMSS |
| Mobile Client | iOS; Android |
| Security | Trusted execution; Digest; Security logs; WSSE; Account lockout; Syslog; 802.1x; IP/MAC filtering; HTTPS; Trusted upgrade; Trusted boot; Generation and importing of X.509 certification |
| Certification |
| Certifications | CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL62368-1 & CAN/CSA C22.2 No. 62368-1-14, UL 50E NEMA Type 4X (optional) |
| Port |
| RS-485 | 1 (baud rate range:1200 bps–115200 bps) |
| Audio Input | 1 channel (terminal) |
| Audio Output | 1 channel (terminal) |
| Alarm Input | 3 channels in: wet contact, 5mA 3V–5V DC |
| Alarm Output | 2 channels out: dry contact, 1,000mA 30V DC/500mA 50V AC |
| Analog Output | 1 channel (CVBS output: built-in 2 pin (testing)) |
| Power Output | 12 VDC power output, max. current 165 mA, peak current 700 mA |
| Power |
| Power Supply | 12 VDC/24 VAC/PoE+ (802.3at)/ePoE |
| Dual Power Backup | When the power adapter and PoE provide power at the same time, disconnect one of them. The device will continue to work, but will not restart. |
| Power Consumption | Basic: 4.1 W (12 VDC); 5.2 W (24 VAC); 5 W (PoE)
Max. (Focus+WDR+ Intelligence on+IR on): 12.9 W (12 VDC); 15.8 W (24 VAC); 15.9 W (PoE)
Heating: 3 W (12 VDC); 3.8 W (24 VAC); 3.9 W (PoE) |
| Environment |
| Operating Temperature | –40 °C to +60 °C (–40 °F to +140 °F) |
| Operating Humidity | ≤95% |
| Storage Temperature | –40 °C to +60 °C (–40 °F to +140 °F) |
| Storage Humidity | 10%–95% (RH), non-condensing |
| Protection | IP67; IK10 |
| Anti-corrosion Level | Moderate Protection (Only supported by -ATC model) *Los productos cuentan con protección anticorrosiva de alta calidad, lo que los hace ideales para entornos con requisitos estándar de resistencia a la corrosión. Funcionan de forma fiable a una distancia de 2 km (1,24 mi) o superior en zonas costeras y en lugares expuestos a la lluvia ácida . |
| Estructura |
| Material de la carcasa | Metal |
| Dimensiones del producto | Φ158 mm × 129,1 mm (6,22" × Φ5,08") |
| Peso neto | 1,1 kg (2,43 libras) |
| Peso bruto | 1,6 kg (3,53 libras) |
