| Camera |
| IR On/Off Control | Automatic |
| Low electric level | Connect to the ground. |
| IR LEDs Number | 1 (IR light) |
| IR Type | IR |
| Image sensor | 1/2.8”CMOS |
| Electronic shutter | PAL: 1/25s–1/100, 000s NTSC: 1/30s–1/100, 000s |
| Lens angle | Vertical: -45°–45° |
| Effective Pixels | 2MP |
| SNR | 42dB |
| Fill Light Distance | 20m |
| Max Resolution | 1080P (1920 × 1080) |
| Minimum Illumination | 0.02Lux/F2.0 30IRE, 0Lux IR on |
| WB | Auto/Manual |
| BLC | Support |
| Mirror | Support |
| WDR | DWDR |
| Day/Night Switch | ICR auto switch |
| Lens |
| Aperture Control | Fixed aperture |
| Min Photographic Distance | 0.5m |
| Aperture | F1.9 |
| Focal Length | 2.0mm |
| Lens Mount | M12 |
| Lens Type | Fixed focal |
| Field of view (FOV) | Horizontal: 143.2°; Vertical: 76.6°: Diagonal: 170.2° |
| Video |
| Frame rate | CVI PAL 1080P; 25fps, 720P@ 25fps; MJPEG: 1080P; 30fps, 720P@ 30fps |
| Gain control | Automatic |
| Resolution | 1080P(1920×1080); 720P(1280×720) |
| Smart Illumination | Support |
| DORI distance | D: 49.7m; O: 19.9m; R: 9.9m; I: 5.0m |
| Video Format | PAL/NTSC |
| Video Type | CVI/TVI/AHD/CVBS |
| IR LED | Support |
| Image Adjustment | Color mode: standard, soft, vivid, warm and cold. Supports adjustments in between sharpness, brightness, contrast, saturation, gamma curve, 2D and 3D noise reduction. |
| Exposure Mode | Auto/manual/Regional exposure, Exposure Level: 0-15 |
| Anti-flicker | Outdoor |
| Power |
| Power Supply | 9V-16V DC |
| Power Consumption | < 5W |
| Port |
| Power | 4-pin aviation port |
| Audio Input | Support |
| Environment |
| Storage temperature | -40°C to +60°C (-40°F to 140°F) |
| Operating Temperature | -40°C to +60°C (-40°F to 140°F) |
| Protection Grade | IP67 |
| Operating Humidity | < 95% (non-condensing) |
| Structure |
| Packing Dimensions | 155mm × 155mm × 135mm (6.10'' × 6.10'' ×5.31'') |
| Product Dimensions | 90.0mm × 110.6mm × 65mm (3.54'' × 4.35'' ×2.56'')(with bracket) |
| Net Weight | 0.372 kg (0.82 lb) |
| Casing Material | Metal |
