Camera |
Image Sensor | 1/2.7 inch CMOS |
Max. Resolution | 1920 (H) x 1080 (V) |
Pixel | 2MP |
Scanning System | Progressive |
Electronic Shutter Speed | PAL: 1/25 s–1/100000 s
NTSC: 1/30 s–1/100000 s |
S/N Ratio | >65 dB |
Min. Illumination | 0.02 Lux/F2.0, 30IRE, 0 Lux IR on |
Illumination Distance | 20 m (65.6 ft) |
Illuminator On/Off Control | Auto; manual |
Illuminator Number | 8 (IR) |
Pan/Tilt/Rotation Range | Pan: –30° to 30° Tilt: 0° to 80° Rotation: 0° to 360° |
Lens |
Lens Type | Fixed-focal |
Mount Type | M12 |
Focal Length | 2.8 mm |
Max. Aperture | F2.0 |
Field of View | H: 106°; V: 55°; D: 126° |
Iris Type | Fixed iris |
Close Focus Distance | 0.5 m (1.64 ft) |
DORI Distance | | Detect | Observe | Recognize | Identify |
2.8 mm | 38.6 m (126.6 ft) | 15.4 m (50.5 ft) | 7.7 m (25.3 ft) | 3.9 m (12.8 ft) |
Video |
Frame Rate | CVI: 1080p@25/30fps; 720p@25/30fps; 720p@50/60fps;
AHD: 1080p@25/30fps; 720p@25/30fps;
TVI: 1080p@25/30fps; 720p@25/30fps; 720p@50/60fps;
CVBS: 960H |
Resolution | 1080p (1920 × 1080); 720p (1280 × 720); 960H (960 × 576/960 × 480) |
Day/Night | Auto switch by ICR |
BLC | BLC/HLC/DWDR |
WDR | DWDR |
White Balance | Auto; manual |
Gain Control | Auto; manual |
Noise Reduction | 2D NR |
Smart IR | Yes |
Mirror | Off/On |
Privacy Masking | Off/On (8 area, rectangle) |
Certifications |
Certifications | CE/FCC |
Port |
Audio Interface | Built-in Mic |
Video Output | 1-channel CVI/CVBS/AHD/TVI switchable video output (Aviation connector) |
Aviation Connector Interface | 1-power 2-video ground 3-power ground 4-video |
Power |
Power Supply | 12V ±30% DC |
Power Consumption | Max 2.6W (12V DC, IR on) |
Environment |
Operating Temperature | –40°C to +60°C (–40°F to 140°F); <95% (non-condensation) |
Storage Temperature | –40°C to +60°C (–40°F to 140°F); <95% (non-condensation) |
Protection Grade | IP67, IK10 |
Structure |
Casing | Metal |
Dimensions | Φ106.0 mm × 50.3 mm (Φ4.17" × 1.98") |
Net Weight | 0.33 kg (0.73 lb) |
Gross Weight | 0.47 kg (1.04 lb) |
