| MARCA | ASUS |
| MODELO | ROG STRIX B650E-E GAMING WIFI |
| CHIPSET | AMD B650 |
| TIPO DE SOCKET | AM5 AMD |
| PROCESADORES | AMD COMPATIBLE | Procesador AMD Ryzen 9 SAM5 7XXX
Procesador AMD Ryzen 7 SAM5 7XXX
Procesador AMD Ryzen 5 SAM5 7XXX |
| MEMORIAS RAM | COMPATIBLES | Memoria RAM DDR5 6000 MHz PC5-48000
Memoria RAM DDR5 5600 MHz PC5-44800
Memoria RAM DDR5 5200 MHz PC5-41600
Memoria RAM DDR5 4800 MHz PC5-38400 |
| NUMERO DE SOCKETS DIMM | 4 |
| EXPANSION MAXIMA EN GB | 128 |
| TECNOLOGIA | AMD EXPO
Dual Channel
OptiMem II |
| TIPO DE RAM | DDR5 |
| VIDEO | Revisar caracteristicas del Procesador |
| SONIDO | TECNOLOGIA | ROG SupremeFX 7.1 Surround Sound High Definition |
| CHIPSET | Realtek ALC4080 Codec |
| CANALES | 7.1 |
| CONECTIVIDAD | ETHERNET | CHIPSET | Intel 2.5Gb |
| VELOCIDAD | 10 Mbps
100 Mbps
1000 Mbps
2500 Mbps |
| WIRELESS | CHIPSET | Wi-Fi 6E 2x2 |
| PROTOCOLOS | 802.11ax
802.11ac
802.11n
802.11g
802.11b
802.11a |
| BANDAS DE FRECUENCIA | 6 GHz
5 GHz
2.4 GHz |
| BLUETOOTH VERSION | 5.2 |
| ALMACENAMIENTO SERIAL ATA | NUMERO DE PUERTOS | 4 |
| VELOCIDAD DE TRANSFERENCIA | 6 Gbit/s |
| RAID SATA | RAID 10
RAID 1
RAID 0 |
| ALMACENAMIENTO M.2 | NUMERO TOTAL DE SLOTS M.2 KEY M | 4 |
| DISTRIBUCION DE SLOTS M.2 KEY M | M.2 CONECTADO AL PROCESADOR | 1 PCIe 5.0 x4, tipos 2242/2260/2280/22110
1 PCIe 5.0 x4, tipos 2242/2260/2280
1 PCIe 4.0 x4, tipos 2242/2260/2280 |
| M.2 CONECTADO AL CHIPSET | 1 PCIe 4.0 x4, tipos 2242/2260/2280 |
| RAID PCIE O NVME | RAID 10
RAID 1
RAID 0 |
| SLOTS DE EXPANSION | CONECTADO AL PROCESADOR | 2 PCI Express x16 slot, PCIe 5.0 modo x16 |
| CONECTADO AL CHIPSET | 1 PCI Express x16 slot, PCIe 4.0 modo x4 |
| PUERTOS INTERNOS | FRONT PANEL AUDIO HEADER | 1 |
| USB 3.2 GEN 2 TIPO-C HEADER | 1 |
| USB 3.2 GEN 1 HEADER | 2 |
| USB 2.0 HEADER | 4 |
| PUERTOS BACK PANEL | USB 3.2 GEN 2X2 TIPO-C | 1 |
| USB 3.2 GEN 2 TIPO-C | 1 |
| USB 3.2 GEN 2 TIPO-A | 6 |
| USB 2.0 TIPO-A | 4 |
| HDMI | 1 |
| DISPLAYPORT | 1 |
| RJ-45 | 1 |
| AUDIO JACKS | 5 |
| OPTICAL S/PDIF OUT | 1 |
| WI-FI / BLUETOOTH ANTENNA | 2 |
| BOTON BIOS FLASHBACK | 1 |
| BOTON CLEAR CMOS | 1 |
| BIOS | AMI BIOS UEFI |
| FACTOR DE FORMA Y DIMENSIONES | FACTOR DE FORMA | ATX |
| DIMENSIONES | 30.5cm x 24.4cm |
| PRESENTACION | CAJA |
| CONECTORES FUENTE POWER | 1 x 24-pin ATX Main Power | 1 |
| 1 x 8-pin ATX 12V power | 2 |
