Hardware
|
|
Included Power Adapter
|
No
|
|
PoE
|
Yes
|
|
Ethernet Port
|
2
|
|
Optical Port
|
2
|
|
Ethernet Port Speed
|
10 Mbps/100 Mbps/1000 Mbps
|
|
Optical Port Speed
|
1000 Mbps
|
|
Console Port
|
1
|
|
Power Supply Mode
|
48 V–57 V DC
|
|
Operating Temperature
|
–40 °C to +75°C (–40 °F to +167 °F)
|
|
Operating Humidity
|
10%–90% (RH)
|
|
Power Consumption
|
Idling: ≤ 9 W
Full load: 120 W
|
|
Performance
|
|
Layer
|
L2
|
|
Managed
|
Yes
|
|
Switching Capacity
|
14 Gbps
|
|
Packet Forwarding Rate
|
5.95 Mpps
|
|
Packet Buffer Size
|
1.75 Mbits
|
|
Communication Standard
|
IEEE 802.3i; IEEE 802.3u; IEEE 802.3ab; IEEE 802.3x; IEEE 802.3z
|
|
MAC Table Size
|
4K
|
|
PoE
|
|
PoE Protocol
|
IEEE 802.3af (PoE); IEEE 802.3at (PoE+); Hi-PoE; IEEE 802.3bt
|
|
PoE Power
|
Port 1-2: ≤ 90 W
Total: ≤ 120 W
|
|
PoE Power Consumption Management
|
Power consumption management
PoE power on and off
Power off when PoE power is overloaded
Green PoE
|
|
PoE Pin Assignment
|
1, 2, 4, 5 (V+), 3, 6, 7, 8 (V-)
|
|
Long Distance PoE Transmission
|
Yes
|
|
Jumbo Frame
|
9,000 bytes
|
|
Spanning Tree Protocol
|
STP; RSTP; MSTP; ERPS
|
|
VLAN Function
|
Yes
|
|
Flow Control
|
IEEE 802.3X-based flow control (full-duplex)
|
|
Link Aggregation
|
Static link aggregation; LACP
|
|
Port Mirroring
|
Multiple-to-one port mirroring
|
|
Multicast
|
Yes
|
|
DHCP Function
|
DHCP client
DHCP-Server
DHCP-Snooping
|
|
Security
|
IEEE 802.1x
ACL
Loop protection
|
|
QoS
|
CoS-based QoS
8 output queue for each port
Port shaping
DSCP-based QoS
|
|
Maintenance
|
Uploading/downloading configuration files
Online upgrade
System logs
|
|
Device Management
|
Web (HTTP and HTTP protocol); Telnet; SNMP V1/V2C/V3; CLI
|
|
General
|
|
Statics Protection
|
Air discharge: 8 kV
Contact discharge: 6 kV
|
|
Lighting Protection
|
Common mode: 6 kV
Differential mode: 4 kV
|
|
Net Weight
|
0.60 kg (1.3 lb)
|
|
Gross Weight
|
0.80 kg (1.8 lb)
|
|
Product Dimensions
|
94.4mm × 53.5 mm × 135 mm (3.7” × 2.11”× 5.31") (L × W × H)
|
|
Packing Dimensions
|
254 mm × 187 mm × 101 mm (10.0" × 7.4" × 4.0") (L × W × H)
|
