Cámara
|
|
Sensor de imagen
|
Canal de visión general: CMOS de 1/2,7"; Canal de detalle: CMOS de 1/2,8"
|
|
Píxel
|
Canal de visión general: 8 MP; Canal de detalle: 4 MP
|
|
Máxima resolución
|
Canal de vista general: 4096 (H) × 1860 (V); Canal de detalle: 2560 (H) × 1440 (V)
|
|
memoria de sólo lectura
|
Canal de descripción general: 4 GB; Canal de detalle: 4 GB
|
|
RAM
|
Canal de descripción general: 2 GB; Canal de detalle: 1 GB
|
|
Velocidad de obturación electrónica
|
1 s–1/30.000 s
|
|
Sistema de escaneo
|
Progresivo
|
|
Iluminación mínima
|
Canal de vista general:
0,005 lux a F1,4 (color, 30 IRE);
0,0005 lux a F1,4 (blanco y negro, 30 IRE);
0 lux (iluminador activado).
Canal de detalle:
0,005 lux a F1,6 (color, 30 IRE);
0,0005 lux a F1,6 (blanco y negro, 30 IRE);
0 lux (iluminador activado).
|
|
Distancia de iluminación
|
Canal de visión general: 30 m (98,43 pies) (IR); 30 m (98,43 pies) (luz blanca); Canal de detalle: 100 m (328,08 pies) (IR); 50 m (131,23 pies) (luz blanca)
|
|
Control de encendido y apagado del iluminador
|
Canal de descripción general:
Manual; Automático; Desactivado
Canal de detalle:
Prioridad de zoom; Manual; Automático; Desactivado
|
|
Número de iluminador
|
Canal de visión general: 2 (luz infrarroja); 2 (luz blanca); Canal de detalle: 2 (luz infrarroja); 2 (luz cálida)
|
|
Lente
|
|
Longitud focal
|
Canal de visión general: 2,8 mm; Canal de detalle: 5 mm–125 mm
|
|
Apertura máxima
|
Canal de visión general: F1.4; Canal de detalle: F1.6-F3.6
|
|
Campo de visión
|
Canal de vista general: H: 180°; V: 86°; Canal de detalle: H: 51,9°–3,0°; V: 39,7°–2,2°; D: 63,1°–3,7°
|
|
Zoom óptico
|
Canal de descripción general: NA; Canal de detalle: 25×
|
|
Control de enfoque
|
Automático; manual; semiautomático
|
|
Distancia de enfoque cercana
|
Canal de vista general: 0,6 m (1,97 pies); Canal de detalle: 0,1 m–0,5 m (0,33"–1,64")
|
|
Iris Control
|
Canal de visión general: NA; Canal de detalle: Automático; manual; prioridad de iris
|
|
Distancia DORI
|
Detectar
|
Detectar
|
Observar
|
Reconocer
|
Identificar
|
|
Canal de descripción general:
2,8 milímetros
|
56,0 m (183,72 pies)
|
22,4 m (73,49 pies)
|
11,2 metros
(36,74 pies)
|
5,6 metros
(18,37 pies)
|
|
Canal de detalle:
EN
|
100,0 m (328,08 pies)
|
40,0 m (131,23 pies)
|
20,0 metros
(65,62 pies)
|
10,0 metros
(32,81 pies)
|
|
Canal de detalle:
T
|
2500,0 m (8202,00 pies)
|
1000,0 m (3280,80 pies)
|
500,0 metros
(1640,40 pies)
|
250,0 metros
(820,20 pies)
|
| DORI (Detect, Observe, Recognize, Identify) is a standard system (EN-62676-4) for defining the ability of a person viewing the video to distinguish persons or objects within a covered area. The numbers in this table do not reflect intelligent function distances. For intelligent function distances, refer to installation and commissioning manual/project design tool. |
|
PTZ
|
|
|
Pan/Tilt Range
|
Pan: 0° to 360° endless
Tilt: –15° to +90°, auto flip 180°
|
|
Manual Control Speed
|
Pan: 0.1°/s–180°/s;
Tilt: 0.1°/s–90°/s
|
|
Preset Speed
|
Pan: 0.1°/s–180°/s;
Tilt: 0.1°/s–90°/s
|
|
Preset
|
300
|
|
Tour
|
8 (up to 32 presets per tour)
|
|
Pattern
|
5
|
|
Scan
|
5
|
|
Power-off Memory
|
Yes
|
|
Idle Motion
|
Preset; Pattern; Tour; Scan
|
|
Intelligence
|
|
|
IVS (Perimeter Protection)
|
Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; human alarm classification; linkage tracking
|
|
Smart Tracking
|
WizTracking: Xinghan large-scale AI models-driven human & vehicle tracking.
Relay tracking: X-SPANS series only. Tracking continues after target exits overview channel until target leaves scene.
Linkage tracking: X-SPANS series only. Tracks only targets visible in overview channel.
|
|
SMD
|
SMD4.0
|
|
Acupick
|
Uses deep learning algorithms and works with backend devices to accurately match targets, such as people and motor vehicles, and search through live and recorded videos to quickly locate targets
(Overview channel support)
|
|
Auto Patrol
|
After an IVS alarm is triggered, it can link with up to 5 presets or scan to patrol the key areas. IVS can be enabled with SMD at the same time.
|
|
Active Deterrence
|
|
|
Light Warning
|
Red-Blue light warning;
Flash duration: 5 s–30 s;
Flash frequency: high, medium, low
|
|
Sound Warning
|
Offers 11 sound alarm and 10 custom sound alarms can be imported.
Sound can be set from 0%–100%.
Play times can be set from 1-10.
|
|
Video
|
|
|
Video Compression
|
Smart H.265+;H.265;Smart H.264+;H.264B;H.264M;H.264H;MJPEG(Sub Stream 1)
|
|
Streaming Capability
|
3 streams
|
|
Resolution
|
Overview channel: 8M (4096 × 1860); 2M (2048 × 928); 1080p (1920 × 1080); 720p (1280 × 720); 1024 × 448; D1 (704 × 576/704 × 480);VGA (640 × 480);CIF (352 × 288/352 × 240); Detail channel: 4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480);VGA (640 × 480); CIF (352 × 288/352 × 240)
|
|
Video Frame Rate
|
Overview channel:
Main stream: 4096 × 1860 @(1–25/30 fps)
Sub stream 1: 1024 × 448/D1/VGA/CIF @(1–25/30 fps)
Sub stream 2: 2048 × 928/1080p/1.3M/720p @(1–25/30 fps);
Detail channel:
Main stream: 4M/3M/1080p/1.3M/720p @(1–25/30 fps)
Sub stream 1: D1/VGA/CIF @(1–25/30 fps)
Sub stream 2: 1080p/1.3M/720p/ @(1–25/30 fps)
|
|
Bit Rate Control
|
CBR/VBR
|
|
Video Bit Rate
|
Overview channel:
H264: 128 kbps–16,384 kbps
H265: 51 kbps–13,312 kbps;
Detail channel:
H264: 96 kbps–16,384 kbps
H265: 38 kbps–10,240 kbps
|
|
Day/Night
|
Overview channel: Auto; Color; B/W; Electronic
Detail channel: Auto; Color; B/W; Electronic
|
|
BLC
|
Yes
|
|
WDR
|
Overview channel: DWDR; Detail channel: 120 dB
|
|
HLC
|
Yes
|
|
White Balance
|
Overview channel: Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp
Detail channel: Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp
|
|
Gain Control
|
Overview channel: Auto; manual; gain prio
Detail channel: Auto; manual; gain prio
|
|
Noise Reduction
|
Overview channel: 2D NR; 3D NR
Detail channel: Auto: 2D NR; 3D NR
|
|
Motion Detection
|
Yes
|
|
Region of Interest (RoI)
|
Yes
|
|
Image Stabilization
|
Overview channel: NA
Detail channel: Electronic Image Stabilization (EIS)
|
|
Defog
|
Overview channel: Electronic
Detail channel: Electronic
|
|
Digital Zoom
|
Overview channel: NA;
Detail channel: 16×
|
|
Image Rotation
|
Overview channel: NA
Detail channel: 180
|
|
S/N Ratio
|
Overview channel: ≥55 dB
Detail channel: ≥55 dB
|
|
Privacy Masking
|
Up to 24 areas can be set, with up to 8 areas in the
same view Multiple colors and mosaic available
|
|
Audio
|
|
|
Audio Compression
|
PCM, G.711A, G.711Mu, G.726, MPEG2-Layer2, G.722.1, G.729
|
|
Network
|
|
|
Network Port
|
RJ-45 (100/1,000 Base-T)
|
|
Network Protocol
|
HTTP; HTTPS; TCP/IP; IPv4; RTSP; UDP; SMTP; NTP; DHCP; DNS; DDNS; IPv6; 802.1x; SSL; QoS; FTP; UPnP; ICMP; SNMP; IGMP; ARP; RTCP; RTP; PPPoE; RTMP; Bonjour; NFS
|
|
Interoperability
|
ONVIF (Profile S & Profile G & Profile T);CGI;SDK;P2P
|
|
Streaming Method
|
Unicast/Multicast
|
|
User/Host
|
20 (total bandwidth: 64 M)
|
|
Storage
|
Micro SD card (512 GB); FTP/SFTP; NAS
|
|
Browser
|
web5.0:
IE 9 and later versions;
Chrome 41 and later versions;
Firefox 52 and later versions;
Safari 10 and later versions
|
|
Management Software
|
DMSS; DSS Pro
|
|
Mobile Client
|
iOS; Android
|
|
Certification
|
|
|
Certifications
|
CE: EN 50130-4
EN 55032
EN 55035
EN 61000-3-3
EN IEC 61000-3-2
EN 62368-1
|
|
Port
|
|
|
Audio Input
|
1 channel (LINE IN, bare wire)
|
|
Audio Output
|
1 channel (LINE OUT,bare wire;built-in speaker (mutually exclusive))
|
|
Alarm Input
|
2 (on-off value input: 0–5 VDC)
|
|
Alarm Output
|
1 channel
|
|
Alarm Linkage
|
Capture; recording; send email; preset; tour; pattern; alarm digital output; audio; warning light
|
|
Alarm Event
|
Motion/tampering detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection
|
|
Power
|
|
|
Power Supply
|
12 VDC, 3 A ± 10%;PoE (802.3at)
|
|
Power Consumption
|
Básico: 14 W;
Máx.: 25 W (iluminador + cristal calefactor + sirena y luz de disuasión activa + ICR + PTZ)
|
|
Adaptador de corriente
|
Opcional
|
|
Ambiente
|
|
|
Temperatura de funcionamiento
|
–40 °C a +65 °C (–40 °F a +149 °F)
|
|
Humedad de funcionamiento
|
≤95%
|
|
Protección
|
IP66; a prueba de rayos TVS 6000 V; protección contra sobretensiones; protección contra transitorios de tensión
|
|
Estructura
|
|
|
Dimensiones del producto
|
194,2 mm × 160 mm × 311 mm (7,65" × 6,30" × 12,24") (largo × ancho × alto)
|
|
Peso neto
|
3,1 kg (6,83 libras)
|
|
Peso bruto
|
4,6 kg (10,14 libras)
|
