Cámara
|
|
Sensor de imagen
|
CMOS de 1/2,7"
|
|
Máxima resolución
|
2688 (alto) × 1520 (vertical)
|
|
memoria de sólo lectura
|
128 MB
|
|
RAM
|
512 MB
|
|
Sistema de escaneo
|
Progresivo
|
|
Velocidad de obturación electrónica
|
Automático/Manual 1/3 s–1/100.000 s
|
|
Iluminación mínima
|
0,003 lux a F1.0 (color, 30 IRE)
0,0003 lux a F1.0 (blanco y negro, 30 IRE)
0 lux (iluminador encendido)
|
|
Relación señal/ruido
|
﹥ 56 dB
|
|
Distancia de iluminación
|
Hasta 30 m (98,43 pies) (IR)
Hasta 30 m (98,43 pies) (luz cálida)
|
|
Control de encendido y apagado del iluminador
|
Auto; manual
|
|
Número de iluminador
|
1 (LED IR)
1 (luz cálida)
|
|
Ajuste del ángulo
|
Panorámica: 0°–360°
Inclinación: 0°–78°
Rotación: 0°–360°
|
|
Lente
|
|
Tipo de lente
|
Focal fijo
|
|
Tipo de montaje
|
M12
|
|
Longitud focal
|
2,8 mm; 3,6 mm
|
|
Campo de visión
|
2,8 mm: Alto: 101°; V: 53°; Profundidad: 120°
3,6 mm: Alto: 82°; V: 44°; Re: 96°
|
|
Tipo de iris
|
Fijado
|
|
Distancia de enfoque cercana
|
2,8 mm: 1,5 m (4,92 pies)
3,6 mm: 2,2 m (7,22 pies)
|
|
Distancia DORI
|
Lente
|
Detectar
|
Observar
|
Reconocer
|
Identificar
|
|
2,8 milímetros
|
66,0 m (216,54 pies)
|
26,4 metros
(86,61 pies)
|
13,2 metros
(43,31 pies)
|
6,6 metros
(21,65 pies)
|
|
3,6 milímetros
|
78,0 m (255,91 pies)
|
31,2 metros
(102,36 pies)
|
15,6 metros
(51,18 pies)
|
7,8 metros
(25,59 pies)
|
|
Intelligent
|
|
IVS (Perimeter Protection)
|
Tripwire; intrusion (Support the classification and accurate detection of vehicle and human)
|
|
SMD 4.0
|
Less false alarm, longer detection distance
|
|
Smart Search
|
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos.
|
|
Quick Pick
|
With AI NVR, quickly pick up the human/vehicle targets that users are interested in from SMD events
|
|
AI SSA
|
Adopt deep learning algorithms to adjust the parameters of the image to suit the conditions.
|
|
Video
|
|
Video Compression
|
H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)
|
|
Smart Codec
|
Smart H.265+; Smart H.264+
|
|
AI Coding
|
AI H.265; AI H.264
|
|
Video Frame Rate
|
Main stream: 2688 × 1520@ (1 fps–30 fps)
Sub stream: 704 × 576@(1 fps–25 fps)/704 × 480@(1 fps–30 fps)
Third stream: 1920 × 1080@ (1 fps–30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
|
|
Stream Capability
|
3 streams
|
|
Resolution
|
4M (2688 × 1520/2560 × 1440); 3M (2304×1296/2048 × 1536); 1080P (1920×1080); 1.3M (1280 × 960); 720P (1280×720); D1 (704× 576/704×480); VGA(640 × 480); CIF (352×288/352×240)
|
|
Bit Rate Control
|
CBR/VBR
|
|
Video Bit Rate
|
H.264: 32kbps–8192 kbps
H.265:12kbps–8192 kbps
|
|
Day/Night
|
Auto (ICR)/Color/B/W
|
|
BLC
|
Yes
|
|
HLC
|
Yes
|
|
WDR
|
120 dB
|
|
Scene Self-adaptation
|
Yes
|
|
White Balance
|
Auto; natural; street lamp; outdoor; manual; regional custom
|
|
Gain Control
|
Auto; manual
|
|
Noise Reduction
|
3D NR
|
|
Motion Detection
|
OFF/ON (4 areas)
|
|
Region of Interest (RoI)
|
Yes (4 areas)
|
|
Smart Illumination
|
Yes
|
|
Defog
|
Yes
|
|
Image Rotation
|
0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower)
|
|
Mirror
|
Yes
|
|
Privacy Masking
|
8 areas
|
|
Audio
|
|
Built-in MIC
|
Yes, built-in dual Mic
|
|
Built-in speaker
|
Yes, built-in speaker
|
|
Audio Compression
|
PCM; G.711a; G.711Mu; G.726; G.723
|
|
Alarm
|
|
Alarm Event
|
No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; scene changing; audio detection; voltage detection; external alarm; SMD; security exception
|
|
Network
|
|
Network
|
RJ-45 (10/100 Base-T)
|
|
SDK and API
|
Yes
|
|
Cyber Security
|
Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade
|
|
Protocol
|
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; SNMP; P2P
|
|
Interoperability
|
ONVIF (Profile S;Profile G;Profile T); CGI
|
|
User/Host
|
20 (Total bandwidth: 72 M)
|
|
Storage
|
FTP; SFTP; Micro SD card (Support max. 256 G); NAS
|
|
Browser
|
IE: IE8/9/11
Chrome
Firefox
|
|
Management Software
|
Smart PSS; DSS; DMSS
|
|
Mobile Phone
|
iOS; Android
|
|
Certification
|
|
Certification
|
CE-LVD: EN 62368-1;
CE-EMC: Directiva de compatibilidad electromagnética 2014/30/UE;
FCC: 47 CFR FCC Parte 15, Subparte B;
UL/CUL:UL62368-1 y CAN/CSA C22.2 n.° 62368-1-14
|
|
Puerto
|
|
Entrada de audio
|
1 canal (puerto RCA)
|
|
Salida de audio
|
1 canal (puerto RCA)
|
|
Entrada de alarma
|
1 canal de entrada: 5 mA 3 V–5 VCC
|
|
Salida de alarma
|
1 canal de salida: 300 mA 12 VCC
|
|
Fuerza
|
|
Fuente de alimentación
|
12 VCC/PoE (802.3af)
|
|
Consumo de energía
|
Básico: 3,7 W (12 VCC); 4,8 W (PoE)
Máx. (corriente de extracción + luz de advertencia + altavoz + luz cálida encendida): 8,3 W (CC 12 V) 8,8 W (POE)
|
|
Ambiente
|
|
Condiciones de funcionamiento
|
–40 °C a +60 °C (–40 °F a +140 °F)/Menos del 95 % de humedad relativa
|
|
Condiciones de almacenamiento
|
–40 °C a +60 °C (–40 °F a +140 °F)
|
|
Grado de protección
|
IP67
|
|
Estructura
|
|
Caja
|
Metal
|
|
Dimensiones
|
110,9 mm × Φ122,0 mm (4,37" × Φ4,80")
|
|
Peso neto
|
745 g (1,64 libras)
|
|
Peso bruto
|
915 g (2,02 libras)
|
