Cámara
|
|
Sensor de imagen
|
CMOS de 1/2,9"
|
|
Máxima resolución
|
2688 (alto) × 1520 (vertical)
|
|
memoria de sólo lectura
|
128 MB
|
|
RAM
|
128 MB
|
|
Sistema de escaneo
|
Progresivo
|
|
Velocidad de obturación electrónica
|
Automático/Manual 1/3 s–1/100.000 s
|
|
Iluminación mínima
|
0,006 Lux a F1.6 (color, 30 IRE)
0,0006 Lux a F1.6 (blanco y negro, 30 IRE)
0 lux (iluminador encendido)
|
|
Relación señal/ruido
|
>56 dB
|
|
Distancia de iluminación
|
30 m (98,43 pies) (LED infrarrojo)
|
|
Control de encendido y apagado del iluminador
|
Auto; manual
|
|
Número de iluminador
|
1 (LED infrarrojo)
|
|
Rango de giro/inclinación/rotación
|
Panorámica: 0°–360°
Inclinación: 0°–90°
Rotación: 0°–360°
|
|
Lente
|
|
Tipo de lente
|
Focal fijo
|
|
Montura de lente
|
M12
|
|
Longitud focal
|
2,8 mm; 3,6 mm
|
|
Apertura máxima
|
F1.6
|
|
Campo de visión
|
2,8 mm: Alto: 95°; Ancho: 52°; Profundidad: 114°;
3,6 mm: Alto: 78°; Ancho: 41°; Profundidad: 94°
|
|
Iris Control
|
Fijado
|
|
Distancia de enfoque cercana
|
2,8 mm: 0,9 m (2,95 pies);
3,6 mm: 1,6 m (5,25 pies)
|
|
Distancia DORI
|
Lente
|
Detectar
|
Observar
|
Reconocer
|
Identificar
|
|
2,8 milímetros
|
63,6 m
(208,66 pies)
|
25,4 m
(83,33 pies)
|
12,7 m
(41,67 pies)
|
6,4 m
(20,99 pies)
|
|
3,6 milímetros
|
85,4 m
(280,18 pies)
|
34,2 m
(112,20 pies)
|
17,1 m
(56,10 pies)
|
8,5 m
(27,89 pies)
|
| DORI (Detectar, Observar, Reconocer, Identificar) es un sistema estándar (EN-62676-4) que define la capacidad de una persona que visualiza el vídeo para distinguir personas u objetos dentro de un área cubierta. Los valores de esta tabla no reflejan las distancias de las funciones inteligentes. Para conocer las distancias de las funciones inteligentes, consulte el manual de instalación y puesta en marcha o la herramienta de diseño de proyectos. |
|
Inteligencia
|
|
IVS (Protección Perimetral)
|
Intrusión, cable trampa (las dos funciones respaldan la clasificación y la detección precisa de vehículos y personas)
|
|
Búsqueda inteligente
|
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos
|
|
Video
|
|
Video Compression
|
H.264H; H.265; H.264; H.264B; MJPEG (Only supported by the sub stream)
|
|
Smart Codec
|
Smart H.265+; Smart H.264+
|
|
Video Frame Rate
|
Main stream: 2688 × 1520@ (1–20 fps)/2560 × 1440@(1–25/30 fps)
Sub stream: 704 × 576@ (1–25 fps)/704 × 480@ (1–30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
|
|
Stream Capability
|
2 streams
|
|
Resolution
|
4M (2688 × 1520); 4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
|
|
Bit Rate Control
|
CBR/VBR
|
|
Video Bit Rate
|
H.264: 32 kbps–6144 kbps
H.265: 12 kbps–6144 kbps
|
|
Day/Night
|
Auto (ICR)/Color/B/W
|
|
BLC
|
Yes
|
|
HLC
|
Yes
|
|
WDR
|
120 dB
|
|
White Balance
|
Auto; natural; street lamp; outdoor; manual; regional custom
|
|
Gain Control
|
Auto; manual
|
|
Noise Reduction
|
3D NR
|
|
Motion Detection
|
OFF/ON (4 areas, rectangular)
|
|
Region of Interest (RoI)
|
Yes (4 areas)
|
|
Image Rotation
|
0°/90°/180°/270° (Support 90°/270° with 2688 × 1520 resolution and lower)
|
|
Mirror
|
Yes
|
|
Privacy Masking
|
4 areas
|
|
Audio
|
|
Built-in MIC
|
Yes
|
|
Audio Compression
|
G.711a; G.711Mu; PCM; G.726
|
|
Alarm
|
|
Alarm Event
|
No SD card; SD card full; SD card error; network
disconnecton; IP conflict; illegal access; moton
detecton; video tampering; tripwire; intrusion; SMD; voltage detecton; security excepton
|
|
Network
|
|
Network Port
|
RJ-45 (10/100 Base-T)
|
|
SDK and API
|
Yes
|
|
Network Protocol
|
IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP; P2P
|
|
Interoperability
|
ONVIF (Profile S/Profile G/Profile T); CGI
|
|
User/Host
|
6 (Total bandwidth: 36 M)
|
|
Storage
|
FTP; SFTP; Micro SD card (support max. 256 GB)
|
|
Browser
|
IE
Chrome
Firefox
|
|
Management Software
|
DSS; DMSS
|
|
Mobile Client
|
iOS; Android
|
|
Cyber Security
|
Configuration encryption;Trusted execution;Digest;Security logs;WSSE;Account lockout;syslog;Video encryption;802.1x;IP/MAC filtering;HTTPS;Trusted upgrade;Trusted boot;Generation and importing of X.509 certification
|
|
Certification
|
|
Certifications
|
CE-LVD: EN62368-1;
CE-EMC: Electromagnetic Compatibility Directive
2014/30/EU;
FCC: 47 CFR FCC Part 15, Subpart B;
UL/CUL: UL62368-1 & CAN/CSA C22.2 No. 62368-1-14
|
|
Power
|
|
Power Supply
|
12 VDC/PoE (802.3af)
|
|
Power Consumption
|
Basic: 2.5 W (12 VDC); 3.3 W (PoE);
Max. (ICR + H.265 + max. resolution + main stream + IR intensity + WDR + IVS): 4.2 W (12 VDC); 5.1 W (PoE)
|
|
Environment
|
|
Operating Temperature
|
–40 °C to +60 °C (–40 °F to +140 °F)
|
|
Operating Humidity
|
≤95%
|
|
Storage Temperature
|
–40 °C to +60 °C (–40 °F to +140 °F)
|
|
Protection
|
IP67
|
|
Structure
|
|
Casing Material
|
Metal
|
|
Product Dimensions
|
166.2 mm × 70 mm × 70 mm (6.54" × 2.76" × 2.76") (L × W × H)
|
|
Net Weight
|
0.48 kg (1.06 lb)
|
|
Gross Weight
|
0.59 kg (1.30 lb)
|
